Bently Nevada 31000-16-05-00-036-03-00Enclosure Kit Series Probe Housing

Description

Bently Nevada Protective Probe Enclosure

Genuine new Bently Nevada 31000-16-05-00-036-03-00 assembly. This is a complete 31000 Proximity Probe Housing Assembly. Ships in original packing with 12-month warranty via FedEx, UPS, DHL.

Protects your sensitive probe in tough industrial areas. Rated for harsh conditions with water and dust resistance. Includes all necessary fittings for a secure installation. Made in USA for reliable performance.

Need installation advice? Contact us: +86 158 8020 0923 (WhatsApp)

Product Configuration Breakdown

• Main Product: Bently Nevada Proximity Probe Housing Assemblies
• Your Complete Kit: 31000-16-05-00-036-03-00
  • Series: 31000 Base Housing
  • Probe Fit: -16 (For 3300 XL 8 mm probe)
  • Cable Length: -05 (0.5 meter probe cable)
  • Adapter: -00 (No standoff adapter)
  • Probe Reach: -036 (3.6 inch penetration)
  • Fittings: -03 (Plugs, NPT fitting, reducer, cable seal grip)
  • Mounting: -00 (No outer sleeve or retaining nut)

Key Specifications & Features

• Robust Construction:
  • Housing Material: Conductive glass-reinforced PPS plastic.
  • Internal Parts: AISI 304 & 303 stainless steel.
  • Seals: Neoprene O-rings for environmental protection.
• Environmental Protection:
  • Certified Ratings: NEMA 4X & IP66 (dust and water jet resistant).
  • Hazardous Area: Meets CENELEC EN50014 for electrostatic safety.
  • Temperature Range: -51°C to +105°C (-60°F to +221°F).
• Durability & Strength:
  • Impact Strength: Certified to withstand heavy impacts at high and low temperatures.
  • Mechanical Load: Housing supports over 200 lbs of force.
  • Weight: 1.2 kg (2.6 lb) typical.
• Installation Note:
  • Seals differential pressure with the probe’s internal Viton O-ring.
  • Not designed for high internal/external pressure vessels.
  • Retaining Nut Torque: Recommended 29.4 N·m (260 in·lb).

Frequently Asked Questions (FAQ)

Purpose & Selection

• What does this 31000-16-05-00-036-03-00 housing kit do?It provides a sturdy, waterproof enclosure to protect a vibration probe installed in outdoor or wash-down areas of a factory.
• Who should buy this housing assembly?Engineers installing Bently Nevada probes in locations exposed to water, dust, or needing protection from physical knocks.

Compatibility & Use

• Which probe fits inside this housing?This -16 option is configured for a 3300 XL 8 mm diameter probe with a 0.5-meter cable.
• What is the “probe penetration” of 3.6 inches?This is how far the probe tip will extend from the housing mounting surface to reach your measurement target (like a shaft).
• Can this housing be used in explosive areas?Yes. The conductive PPS material meets CENELEC standards for electrostatic safety in hazardous locations.

Ordering & Support

• What is included in the box and how is it shipped?You get the full housing kit as specified. It is brand new with a 12-month warranty. We ship globally using FedEx, UPS, or DHL for fast delivery.
• Are other fitting or penetration options available?Yes. The 31000 series has many options. Contact us to configure a housing for your exact thread and depth requirements.
