Description
Compact Housing for 8mm Probes with Standoff
Get the Bently Nevada 31000-28-05-35-032-03-02 housing kit. This version includes a 3.5-inch standoff extension. It is perfect for mounting your 8 mm probe through thick machine walls or enclosures. The kit comes with all needed fittings for a complete, protected installation.
Part Number Configuration Map
- 31000 – Base Housing Assembly
Feature Breakdown:
- Segment 1: Probe & Cable
- 28: Compatible with 3300 XL 8 mm probes
- 05: Short 0.5 m (20 in) cable at housing
- Segment 2: Dimensions & Hardware
- 35: 3.5-inch stainless steel standoff adapter
- 032: Probe penetrates 3.2 inches into housing
- 03: Complete fittings kit included
- 02: Mounts via 3/4-14 NPT thread
Core Benefits for Your Application
- Space-Bridging Design: The 3.5″ standoff lets you mount the housing away from the measurement point. Ideal for thick casings or insulation.
- Complete Kit: Includes all seals, plugs, reducer, and cable grip. No extra parts to buy.
- Short Exit Cable: The 0.5m cable is perfect for tidy connections inside control panels or tight spaces.
- Extreme Environment Ready: Rated for NEMA 4X, IP66, and hazardous areas. Handles impacts and wide temperatures.
- Industrial Standard: A key member of the 31000 Proximity Probe Housing Assemblies family.
Complete Technical Details
- Product Identification
- Manufacturer: Bently Nevada
- Full Model Number: 31000-28-05-35-032-03-02
- Application: Protective Enclosure for Vibration Probes
- Key Components
- Main Housing: Conductive PPS Plastic
- Standoff Extension: 3.5 inches, Stainless Steel
- Pre-attached Cable: 0.5 meters long
- Fittings Kit: Plugs, Reducer, Cable Seal Grip with Grommets
- Performance & Compliance
- Enclosure Rating: NEMA 4X / IP66 (Dust and Watertight)
- Temperature Range: -51°C to +105°C
- Safety Certification: BASEEFA & CSA Impact Certified, CENELEC EN50014
- Mounting: 3/4-14 NPT Female Thread
- Installation Torque (Nut): 29.4 N·m
How to Install This Housing
- Screw the 3.5-inch standoff into your mounting point.
- Attach the main housing body to the standoff.
- Insert your 8 mm probe so it goes 3.2 inches into the housing.
- Tighten the retaining nut to the specified 29.4 N·m torque.
- Route your probe cable through the correct grommet in the seal grip and tighten.
- Use the provided plugs to close any open ports.
Purchasing & Customer Support
- Quality Guarantee: All products include a 12-month manufacturer warranty.
- Fast Logistics: We ship promptly using reliable carriers like FedEx, UPS, and DHL.
- Designed For: Housing and protecting Bently Nevada 3300 XL 8 mm proximity probes.
- Expert Advice: Reach our technical sales team on WhatsApp at +86 158 8020 0923 for configuration help.
In-Depth FAQs
Understanding the Configuration
- Q: When should I choose a housing WITH a standoff adapter?
- A: Use a standoff when there is material (like insulation, a thick guard, or a double wall) between your mounting surface and the machine surface where you need to measure. The standoff bridges this gap.
Technical Specifications
- Q: What is the difference between “Probe Penetration” and “Standoff Adapter” length?
- A> Probe Penetration (3.2 in) is how far the probe sits inside the housing body. Standoff Adapter length (3.5 in) is how far the housing extends from the mounting point. They are separate measurements that add up to total extension.
- Q: Is the 0.5m cable long enough for my application?
- A> This short cable is designed to exit the housing and connect quickly to an extension cable or a nearby junction box. It is not meant to reach the monitor directly. You will likely need a separate extension cable.
Practical Application & Selection
- Q: Can this housing be used in a high-temperature area above 105°C?
- A> No. The specified temperature limit is 105°C. The plastic material properties and seal integrity are not guaranteed above this temperature. Check the machine surface temperature first.
- Q: From field experience, what is key for a reliable seal with the cable grip?
- A> Ensure the cable outer jacket is clean and round where it passes through the grommet. Any cuts or deformities in the jacket can create a path for moisture to seep in, defeating the IP66 rating.
