Bently Nevada 32000-28-05-05-030-03-02 Series Proximity Probe Housing

Description

Product Overview

This genuine Bently Nevada 32000 series housing securely mounts 3300 XL 8mm Probes. It ensures reliable vibration measurement. Perfect for turbines, compressors, and pumps.

Complete Model Breakdown: 32000-28-05-05-030-03-02

• 32000 – Metric Proximity Probe Housing Series
• 28 – Probe Option
  • Compatible with 3300 XL 8mm probe
  • Includes multiple agency approvals
• 05 – Cable Length Option
  • 0.5 meter (20 inch) probe cable
• 05 – Standoff Adapter Option
  • 50 mm extension adapter
• 030 – Probe Penetration Option
  • Fixed 30 mm penetration depth
• 03 – Fittings Option
  • Two electrical plugs
  • One M20 conduit fitting
  • One cable seal grip for armored cable
• 02 – Mounting Thread Option
  • 3/4-14 NPT pipe thread
  • Required with Standoff Adapter

Technical Specifications

• Brand: Bently Nevada
• Full Model: 32000-28-05-05-030-03-02
• Compatible Probe: 3300 XL 8mm only
• Temperature Range: -51°C to +105°C
• Environmental Rating: IP66 & Type 4X (CSA)
• Hazardous Area: CENELEC EN50014 compliant
• Housing Material: Conductive PPS thermoplastic
• Metal Parts: AISI 304/303 Stainless Steel
• Seal Material: Neoprene O-Ring
• Impact Resistance: 4 Joule certified (BASEEFA)
• Weight: 1.2 kg (2.65 lb)

Installation & Maintenance

• Standard 3/4-14 NPT thread for easy mounting
• Clear 30mm depth setting for consistent installation
• Stainless steel construction reduces maintenance
• All necessary fittings included in package

System Compatibility

• Designed for Bently Nevada 3300 XL 8mm probes
• Integrates with Bently Nevada 3300 monitoring systems
• Conductive housing prevents signal noise

Certifications & Safety

• CSA Type 4X certified
• IP66 rating verified
• BASEEFA impact certification
• CENELEC EN50014 hazardous area rating

Package Contents & Support

• One complete probe housing assembly
• All plugs, fittings, and seal grips
• Stainless steel retaining chain
• 12-month manufacturer warranty
• Global shipping via FedEx, UPS, DHL

Technical support: +86 158 8020 0923

Typical Applications

• Steam/Gas turbine vibration monitoring
• Compressor shaft position measurement
• Large motor and pump bearing protection
• Predictive maintenance systems

Diagnostic Capability

Precise housing enables accurate probe positioning. This ensures reliable vibration data collection. Helps detect unbalance, misalignment, and bearing wear early.

Frequently Asked Questions

General Questions

• What probe fits this housing?
• Only the Bently Nevada 3300 XL 8mm probe.
• Is the probe included?
• No, housing and probe are sold separately.

Model Suffix Questions

• Can I get different cable lengths?
• Yes, contact us for custom suffix “-05-” changes.
• What if my thread is not 3/4-14 NPT?
• Select appropriate “-02-” suffix option during ordering.

Installation Experience

• Any installation tips?
• Use thread sealant. Ensure O-ring is clean. Verify 30mm depth.
• Tools required?
• Standard pipe thread tools and torque wrench.

Purchasing Guidance

• How to verify compatibility?
• Check your probe model and mounting thread size.
• Delivery time?
• Standard units ship in 2-4 weeks.
