Bently Nevada 3300 Ceramic Probe 146054-040-10-02-05 | ATEX Certified Vibration Sensor

Description

Product Introduction

Discover the Bently Nevada 3300 Ceramic Capped Proximity Probe 146054-040-10-02-05, a high-precision sensor for critical vibration and position monitoring. This new, factory-sealed probe ensures reliable performance in demanding industrial environments. It is perfect for predictive maintenance on turbines, compressors, and rotating machinery. Original manufacturer quality with full 12-month warranty.

Download the datasheet for complete specifications:

• Detailed technical drawings
• Full installation guidelines
• System configuration advice
• Compatibility charts

Technical Specifications

• Brand & Model: Bently Nevada 3300 Series, P/N: 146054-040-10-02-05
• Measurement Range: Linear range of 1.52 mm (60 mils).
• Sensitivity (Scale Factor): 7.87 V/mm (200 mV/mil).
• Linearity: ±6.5% over full range.
• Temperature Range: Operates from -51°C to +177°C (-60°F to +351°F).
• Environmental Durability:
  • Probe tip: Wear-resistant alumina ceramic.
  • Case: AISI 304 stainless steel.
  • Pressure Seal: Rated for 34 Bar (500 psi).
• Noise Immunity: Uses 75 Ω coaxial cable for stable signal transmission.
• Probe Resistance: 7.59 ± 0.5 ohms (for 1.0m length).
• Thread Specification: 3/8-24 UNF thread, 0.563″ max engagement.

Ordering Code: 146054-AA-BB-CC-DD

• 146054: 3300 Ceramic Capped Probe, 3/8-24 UNF
• -040 (AA): Overall Case Length = 4.0 inches
• -10 (BB): Cable Length = 1.0 meter (3.3 feet)
• 02 (CC): Connector = Miniature Coaxial ClickLoc
• -05 (DD): Approvals = CSA, ATEX, IECEx

Key Features & Benefits

• Robust & Precise: Ceramic tip resists wear. Provides accurate measurement for machinery health.
• Easy Installation: Standard UNF thread and ClickLoc connector enable quick setup.
• Global Compliance: Carries major safety certifications (ATEX, IECEx) for hazardous areas.
• Superior Compatibility: Designed for seamless use with Bently Nevada 3300 XL monitoring systems.
• Ready to Use: Comes new in original factory packing with all standard accessories.

Frequently Asked Questions (FAQ)

What target material is this probe calibrated for?

The system specifications require an AISI 4140 steel target for guaranteed accuracy.

Can I use this probe in high-pressure environments?

Yes. It is pressure sealed for 34 Bar. Contact us for higher-pressure modifications.

Is the cable length fixed?

This unit has a fixed 1.0-meter cable. Other standard lengths (0.5m, 2m, 5m, 9m) are available.

What is the main advantage of the ceramic cap?

The alumina ceramic tip greatly extends probe life in applications with target rub or abrasive environments.

How does temperature affect the probe?

The probe itself operates in extreme temperatures from -51°C to +177°C. System electronics have a separate range.

Package & Support

• Package Includes: One Bently Nevada 3300 probe (P/N 146054-040-10-02-05), factory documentation.
• Warranty: Full 12-month manufacturer warranty on defects.
• Shipping: We ship worldwide via FedEx, UPS, and DHL for reliable delivery.

Typical Applications: Ideal for monitoring vibration and axial position on gas turbines, steam turbines, fans, pumps, and critical compressors. Enables early fault diagnosis like shaft misalignment and bearing wear.
