Bently Nevada 3300 Ceramic Probe 146054-08-50-00-00 | 5m Vibration Sensor

Description

Product Description

This is a new & original Bently Nevada 3300 Series proximity probe. The part number is 146054-08-50-00-00. It comes in factory packing with a 12-month warranty. The probe has a rugged ceramic cap and a 5.0-meter cable. It is perfect for monitoring shaft vibration and position in turbines, compressors, and other rotating machinery.

Technical Specifications

• Brand & Model: Bently Nevada 3300 Series Ceramic Capped Probe
• Full Part Number: 146054-08-50-00-00
  • 146054: 3300 Ceramic Probe, 3/8-24 UNF thread
  • -08: Case Length = 0.8 inch
  • -50: Cable Length = 5.0 meters (for use with 5m Proximitor only)
  • -00: No connector
  • -00: No agency approval
• Measurement Range: 60 mils (1.52 mm). Linear from 10 to 70 mils.
• Sensitivity (Scale Factor): 200 mV/mil (7.87 V/mm) ±6.5%.
• Probe Tip: Durable Alumina Ceramic (Al2O3).
• Probe Body: AISI 304 Stainless Steel.
• Thread: 3/8-24 UNF. Max engagement 0.563 inch.
• Cable: 75 Ω coaxial, FEP insulated. Length 5.0m.
• DC Resistance: 8.73 ± 0.70 ohms (at 5m length).
• Temperature Range:
  • Operating/Storage: -51°C to +177°C (-60°F to +351°F).
• Environmental Durability:
  • Pressure Seal: Rated for 34 Bar (500 psi) nitrogen.
• Compatibility: Designed for use with 5-meter Bently Nevada 3300 XL Proximitor Sensors. Calibrated for AISI 4140 steel targets.

Installation & Maintenance

• Ensure target material is AISI 4140 steel for specified accuracy.
• Do not exceed the maximum thread engagement depth.
• The system is highly interchangeable. It reduces downtime.
• Check probe resistance before installation for quick health verification.

Certifications & Packaging

• Agency approvals are not specified for this variant (-00).
• Package includes the probe in its original protective factory packing.
• Your order includes a 12-month factory warranty.

Shipping & Delivery

We ship globally via FedEx, UPS, and DHL. Delivery time depends on your location and chosen service.

Typical Applications & Diagnostics

• Applications: Vibration monitoring on gas/steam turbines, compressors, pumps, fans, and generators.
• Diagnostic Capability: This probe is a key part of a system that detects early warning signs of machine faults like unbalance, misalignment, and bearing wear.

Frequently Asked Questions (FAQ)

What is the difference between -00 and -01 agency options?

The -00 option has no formal agency certification. The -01 option includes approvals for use in hazardous areas.

Can I use this 5m probe with a 9m extension cable?

No. The 5m probe is electrically tuned for use only with a 5m Proximitor sensor. Using other lengths will cause measurement errors.

Why is the ceramic cap important?

The ceramic tip resists wear and electrical erosion much better than metal tips. This gives longer life in harsh environments.

From experience, how critical is the target material?

Very critical. The system’s stated accuracy and scale factor are only guaranteed with an AISI 4140 steel target. Other materials will change the output.

How do I check if a used probe is still good?

Measure the DC resistance between the center pin and outer shield. A value far outside the 8.73 ± 0.70 ohm range suggests internal damage.

Is the pressure seal tested on every unit?

Standard units are rated but not 100% tested. For critical high-pressure applications, contact Bently Nevada’s custom department for specific testing.
