Description
330903-00-02-10-11-00: Compact M8 Vibration Probe
New Bently Nevada sensor with FluidLoc cable for wet environments. 20mm ultra-short case design.
Product ID Breakdown
- ┌ 330903: M8 Thread Base
- ├ 00: 0mm unthreaded length
- ├ 02: 20mm case length
- ├ 10: 1.0m cable
- ├ 11: ClickLoc + FluidLoc
- └ 00: No approvals needed
Key Advantages
- Ultra-compact: 20mm case fits space-limited areas
- Chemical-resistant: FluidLoc cable for wet conditions
- Precision sensing: ±0.06mm linearity deviation
- 7.87 V/mm sensitivity (±20%)
Technical Specifications
Electrical
▸ Resistance: 4.2Ω ±0.5
▸ Capacitance: 69.9 pF/m
▸ Frequency: 0-10 kHz
▸ Resistance: 4.2Ω ±0.5
▸ Capacitance: 69.9 pF/m
▸ Frequency: 0-10 kHz
Mechanical
▸ Torque: 5.1 N•m max
▸ Bend radius: 25.4mm
▸ Weight: 14-150g
▸ Torque: 5.1 N•m max
▸ Bend radius: 25.4mm
▸ Weight: 14-150g
Performance
▸ Linear range: 1.5mm
▸ Target size: min 8.9mm
▸ Scale factor: 7.87 V/mm
▸ Linear range: 1.5mm
▸ Target size: min 8.9mm
▸ Scale factor: 7.87 V/mm
Installation Notes
- ▸ Thread engagement: max 12mm
- ▸ Torque: finger tight to 0.56 N•m (5 in•lb)
- ▸ Wiring: Use shielded triad cable (max 305m)
- ▸ Gap setting: optimal at 1.0mm (40 mils)
Certifications
Compatible with 3300 RAM systems – enhanced chemical resistance
Package Contents
- ▸ M8 thread vibration probe
- ▸ 1.0m FluidLoc cable
- ▸ ClickLoc connector with protector
- ▸ 12-month warranty
Global Shipping
FedEx | UPS | DHL – Express options available
FAQ
- Q: Why FluidLoc cable?
▸ Special protection against liquids and chemicals - Q: Minimum target size?
▸ 8.9mm diameter – use 13mm for best accuracy - Q: Compatible with older systems?
▸ Yes – works with 3300 RAM probes and cables
