Bently Nevada 3300 NSv Proximity Probe 330903-00-04-10-02-00

Description

Bently Nevada 3300 NSv Proximity Probe – 1 Meter Cable Version

New factory-sealed vibration sensor with extended reach for flexible installations.

Suffix Configuration Breakdown

• Base Model: 330903 (M8X1 thread)
• First Pair: 00 = 0mm unthreaded length
• Second Pair: 04 = 40mm case length
• Third Pair: 10 = 1.0m cable length
• Fourth Pair: 02 = Standard cable with ClickLoc
• Fifth Pair: 00 = No agency approvals required

Enhanced Technical Specifications

• Electrical Performance:
  • Probe resistance: 4.2Ω ±0.5 (1m cable)
  • Center conductor: 0.220 Ω/m
  • Shield resistance: 0.066 Ω/m
  • Capacitance: 70 pF/m typical
• Environmental Ratings:
  • IP67 equivalent sealing
  • Viton O-ring pressure seal
  • UV-resistant cable jacket
• Mechanical Specifications:
  • Thread engagement: 12mm max
  • Cable weight: 120g/m
  • Vibration tolerance: 15g peak

Installation Guidelines

• Optimal mounting: 1.0mm target gap
• Max angular misalignment: 3°
• Radial offset tolerance: ±0.5mm
• Cable bend radius: >25.4mm
• Installation torque: 5.1 N•m (45 in-lb)

Model Comparison

Performance Data

• Linearity: ±0.06mm across full range
• Frequency Response: ±3dB to 10kHz
• Temperature Sensitivity: 0.02%/°C
• Hysteresis: < 0.5% full scale

Shipping & Packaging

• Factory-sealed anti-static packaging
• 12-month manufacturer warranty
• Global express shipping: FedEx/UPS/DHL
• MSDS documentation included

Technical FAQ

Q: Advantage of 1m cable length?
A: Reduces extension cable needs in tight spaces

Q: Chemical compatibility of standard cable?
A: Resists oils and coolants but not aggressive chemicals

Q: Maximum cable extension?
A: 305m total system length (probe + extension)

Q: Calibration certification available?
A: Traceable NIST calibration optional

Q: Replacement for RAM probes?
A: Direct drop-in replacement with better performance
