Description
Bently Nevada 3300 NSv Probe: Compact Precision Sensor
New M8-thread proximity probe with FluidLoc cable for wet environments. Original factory-packed with 12-month warranty.
Part Number Breakdown
- 330903-
- Base model
- 00
- Unthreaded: 0mm
- 05
- Case length: 50mm
- 50
- Cable: 5.0 meters
- 12
- Connector: ClickLoc + FluidLoc
- 00
- Approvals: Standard
Key Specifications
- Thread Type: M8X1
- Measurement Range: 0.25-1.75mm
- Recommended Gap: 1.0mm (40 mils)
- Voltage Output: -1 to -13 Vdc
- Cable Type: 75Ω FluidLoc coaxial
- Bend Radius: 25.4mm min
Performance Data
- Scale Factor: 7.87 V/mm ±20%
- Accuracy: ±0.06mm deviation
- Response: 0-10 kHz (±3dB)
- Target Size: Min 8.9mm diameter
- Cable Resistance: 5.3Ω ±0.7 (5m)
Installation Guide
- Max thread depth: 12mm
- Recommended torque: 45 in-lb
- Max torque: 65 in-lb
- Seal: Viton O-ring
Cable Specifications
- Center conductor: 0.220 Ω/m
- Shield resistance: 0.066 Ω/m
- Capacitance: 69.9 pF/m
- Max wiring length: 305m
Compatibility
Works with all 3300 NSv systems. Backward compatible with 3300 RAM probes.
Package Includes
- 1x Proximity probe (M8 thread)
- Factory packaging
- 12-month warranty
Shipping
Worldwide via FedEx, UPS, DHL
FAQ
Q: What is FluidLoc cable?
A: Special sealing prevents fluid entry in wet areas.
Q: Minimum target size?
A: 8.9mm diameter. Use 13mm for best results.
Q: Can I bend the cable sharply?
A: Keep bends above 25.4mm radius.
Q: Warranty coverage?
A: 12 months for manufacturing defects.
Q: Chemical resistance?
A: Superior to older 3300 RAM probes.
