Bently Nevada 3300 NSv Proximity Probe 330903-00-05-50-12-05

Description

Bently Nevada 3300 NSv Proximity Probe: Precision Industrial Monitoring

Product Description

New Bently Nevada 330903-00-05-50-12-05 proximity probe with factory warranty. Features M8x1 threading and 5-meter FluidLoc cable with ClickLoc connector. Superior chemical resistance for process compressors. Compatible with legacy 3300 RAM systems.

Key Technical Data

• Brand: Bently Nevada
• Model: 3300 NSv (Full suffix: 330903-00-05-50-12-05)
• Measuring Range: 1.5mm (60 mils)
• Accuracy: ±0.06mm deviation
• Scale Factor: 7.87 V/mm ±12.5%/-20%
• Temp Range: -52°C to +177°C
• Probe Resistance: 5.3Ω ±0.7Ω

Critical Specifications

• Recommended Gap: 1.0mm (40 mils)
• Frequency Response: 0-10 kHz (±3dB)
• Cable Type: 75Ω coaxial FEP insulation
• Thread Torque: 5.1 N•m (45 in•lb)
• Min Target Size: Ø13mm (0.5in)

Installation Guide

• Max Bend Radius: 25.4mm (1.0in)
• Torque Specs: Finger tight + max 0.56 N•m
• Thread Engagement: 12mm for M8x1
• Wiring: 3-conductor shielded triad (max 305m)

Compatibility & Certifications

Electrically interchangeable with 3300 RAM probes. Features Multiple Agency Approvals (option 05). Superior side-view characteristics vs 3000-series probes.

What’s Included

• New probe in factory packaging
• 12-month warranty
• Shipping via FedEx/UPS/DHL

FAQ

Q: Cable length options?
A: Standard 5m (16.4ft), other sizes: 0.5/1/7m

Q: Pressure rating?
A: Viton O-ring seal (contact for pressure testing)

Q: Chemical resistance?
A: Enhanced vs 3300 RAM probes

Need full specifications? Download Datasheet Here
