Bently Nevada 3300 NSv Proximity Probe | 330904-00-10-10-11-00

Description

Bently Nevada 3300 NSv Proximity Probe – 1 Meter Cable (P/N: 330904-00-10-10-11-00)

Product Details

New factory-sealed vibration sensor with 12-month warranty. M8x1 threaded stainless steel body. Ships via FedEx, UPS, DHL.

Complete Model Information

• Base model: 330904 (M8x1 thread with armor)
• Unthreaded length: 00 = 0 mm
• Case length: 10 = 100 mm
• Cable length: 10 = 1.0 meter (39 inches)
• Connector: 11 = ClickLoc with FluidLoc cable
• Certifications: 00 = Standard approvals

Technical Parameters

• Cable resistance: 4.2Ω ±0.5
• Voltage output: -1V to -13V DC
• Temperature range: -62°F to +351°F (-52°C to +177°C)
• Bend radius: Minimum 1 inch (25.4 mm)
• Thread engagement: Maximum 12 mm
• Shield resistance: 0.066 Ω/m
• Capacitance: 69.9 pF/m
• Response speed: 0-10,000 RPM capability

Installation Guide

• Mount with finger tight plus 1/4 turn
• Set measurement gap to 1.0 mm (40 mils)
• Use shielded triad cable for field wiring
• Maximum wiring distance: 1000 feet (305 m)

Compatibility Notes

• Works with 3300 RAM systems
• Fits standard 75Ω coaxial connections
• Better chemical resistance than older probes
• Ideal for tight spaces with 100mm case

Package Contents

• 1 x Proximity probe
• 1 x Connector protector
• Warranty card

Warranty & Shipping

12-month manufacturer warranty
Ships same day via FedEx, UPS, DHL
Global delivery options available

Frequently Asked Questions

• Q: What is the cable material?
  A: FEP-insulated coaxial cable for chemical resistance
• Q: Minimum target size?
  A: Works on shafts down to 8.9mm diameter
• Q: Pressure rating?
  A: Viton sealed for industrial environments
• Q: Replacement for 3300 XL probes?
  A: Yes, fully compatible with same connectors
• Q: Vibration measurement range?
  A: 0.25mm to 1.75mm with linear output
• Q: Maximum installation torque?
  A: 5 in-lb (0.56 N•m) for safe mounting
