Description
Bently Nevada 3300 NSv Proximity Probe: Industrial-Grade Vibration Sensing
Complete Model 330904-08-10-05-02-05 Breakdown
- Base Model: 330904 (NSv Probe, M8X1 thread, armored)
- -08-: 80mm unthreaded section
- -10-: 100mm overall case length
- -05-: 0.5 meter cable (20 inches)
- -02-: ClickLoc connector with standard cable
- -05-: Multiple agency approvals
Technical Performance
| Range | 1.5 mm (60 mils) |
| Accuracy | ±0.06 mm (±2.3 mils) |
| Output | -1 to -13 Vdc |
| Temp Range | -52°C to +177°C |
| Response | 0-10 kHz (±3dB) |
| Cable Resistance | 4.0Ω ±0.5 (0.5m) |
| Min Target Size | 8.9mm diameter |
Installation Guide
- Set gap to 1.0 mm (40 mils)
- Apply 5.1 N•m torque (45 in•lb)
- Max thread engagement: 12 mm
- Min bend radius: 25.4 mm (1.0 in)
Product Advantages
- Stainless steel armor for protection
- Viton O-ring for pressure sealing
- Works with cables up to 305 meters
- Better side-view than older 190 probes
Certifications & Approvals
ATEX, IECEx, CSA certified (Multi-approval suffix -05)
Package Includes
- 3300 NSv proximity probe
- Connector protector
- Factory packaging
- 12-month warranty
Professional FAQ
Q: Cable length options available?
A: 0.5m, 1m, 5m, or 7m cables
Q: Suitable for small shafts?
A: Yes, but scale factor changes below 13mm diameter
Q: Pressure rating information?
A: Contact for custom pressure testing
Q: Compatible with older monitors?
A: Yes, works with 3300 RAM systems
Q: Chemical resistance material?
A: PPS probe tip with stainless steel case
Get Installation Guide
Download full manual for:
- Wiring diagrams
- Gap setting instructions
- Frequency response charts
- Troubleshooting tips
