Description
Bently Nevada 3300 NSv Proximity Probe: Precision Vibration Monitoring
Brand new & factory sealed 330904-08-10-10-11-05 probe with 12-month warranty. Designed for critical vibration measurement in turbines, compressors, and rotating machinery.
Core Specifications
- Brand: Bently Nevada
- Model: 3300 NSv Proximity Probe
- Full Suffix: 330904-08-10-10-11-05
- Range: 1.5 mm (60 mils)
- Accuracy: ±0.06 mm (±2.3 mils)
- Output: -1 to -13 Vdc linear signal
- Temp Range: -52°C to +177°C (-62°F to +351°F)
- Cable: 1.0m armored FEP with ClickLoc connector
Installation Guide
- Gap Setting: 1.0 mm (40 mils) from target
- Torque: Hand tight (max 0.56 N•m)
- Min Bend Radius: 25.4 mm (1.0 in)
- Wiring: Shielded triad cable (max 305m)
Key Features
- M8x1 thread with 80mm unthreaded length
- Enhanced chemical resistance vs. 3300 RAM probes
- Stainless steel case with PPS probe tip
- Fully interchangeable with 3300 RAM systems
Certifications & Compliance
- Multiple agency approvals (-05 suffix)
- Viton O-ring pressure seal
- FluidLoc cable protection
Package Contents
- 330904-08-10-10-11-05 Probe
- Original factory packaging
- 12-month warranty documentation
Shipping & Support
- Global delivery via FedEx, UPS, DHL
- 30-day hassle-free returns
Frequently Asked Questions
Q: Pressure rating for this probe?
Seals differential pressure but not factory-tested. Contact us for custom validation.
Q: Compatible with 3300 RAM systems?
Yes – fully interchangeable electrically/mechanically.
Q: Minimum target size?
8.9mm diameter (13mm recommended).
