Description
Product Overview: Bently Nevada 3300 Proximity Probe
- This is a genuine Bently Nevada 3300 series proximity transducer.
- Part Number: 146054-08-10-00-00
- It features a durable ceramic-capped tip for long life.
- The probe is designed for precise vibration and position measurement.
- Ideal for protecting rotating machinery like turbines and compressors.
- Comes new and original in factory packaging.
Key Features & Benefits
- Superior Durability: Alumina ceramic tip resists wear and corrosion.
- Wide Temperature Range: Operates from -51°C to +177°C reliably.
- High Pressure Rating: Seals up to 34 Bar (500 psi).
- Excellent Linearity: Provides accurate measurement over a 60 mil range.
- Industry Standard: Trusted by engineers worldwide for critical monitoring.
- Easy Integration: Compatible with the entire 3300 monitoring system.
Complete Technical Specifications
- Brand & Model: Bently Nevada 146054-08-10-00-00
- Product Type: 3300 Series Ceramic Capped Proximity Probe
- Thread Size: 3/8-24 UNF
- Probe Case Material: AISI 304 Stainless Steel
- Tip Material: Alumina Ceramic (Al2O3)
- Overall Case Length: 0.8 inches (20.32 mm)
- Total Cable Length: 1.0 meter (3.3 feet)
- Cable Type: 75 Ω coaxial with FEP insulation
- Cable End: No connector (bare leads)
- Nominal DC Resistance: 7.59 Ω ± 0.50 Ω
- Linear Measurement Range: 1.52 mm (60 mils)
- Scale Factor (Sensitivity): 7.87 V/mm ±6.5% (200 mV/mil)
- Pressure Seal Rating: 500 psi (34 Bar) with nitrogen
- Maximum Thread Engagement: 0.563 inches
Ordering Code Breakdown
- The full part number 146054-AA-BB-CC-DD is built like this:
- 146054: Base number for 3300 Ceramic Capped Probe, 3/8-24 UNF thread.
- AA: Case Length
- -08: 0.8 inch overall case length.
- BB: Cable Length
- -10: 1.0 meter total probe length.
- CC: Connector Type
- -00: No connector on cable end.
- DD: Agency Approval
- -00: No special agency approval required.
Environmental & Operational Limits
- Operating/Storage Temperature: -51°C to +177°C (-60°F to +351°F)
- System Accuracy Temp Range: 0°C to +45°C for specified performance.
- Ambient Humidity: Suitable for non-condensing environments.
- Target Material: Calibrated for AISI 4140 steel.
- Required Power Supply: -24 Vdc for the connected monitoring system.
Package Contents
- 1 x Bently Nevada Proximity Probe (146054-08-10-00-00).
- All items are in original factory protective packaging.
- Data sheet or calibration sheet may be included.
Warranty & Global Shipping
- This product includes a full 12-month manufacturer warranty.
- We ship worldwide using express carriers: FedEx, UPS, and DHL.
- Tracking details are provided immediately after dispatch.
Typical Applications
- Shaft vibration monitoring in gas and steam turbines.
- Axial and radial position measurement in compressors.
- Critical machinery protection systems in power generation.
- Rotating equipment in oil, gas, and petrochemical plants.
Frequently Asked Questions
- Q: Is this probe compatible with my existing Bently Nevada 3300 monitor?
- A: Yes, it is designed to work seamlessly with 3300 XL system components.
- Q: Can I cut and solder a connector onto the cable?
- A: Yes, but it must be done carefully to maintain the 75-ohm coaxial integrity.
- Q: What is the difference between ceramic and stainless steel tipped probes?
- A: Ceramic tips are better for environments with potential for rubbing or conductive particles.
- Q: How do I install this probe into a threaded hole?
- A: Hand-tighten first, then use a wrench for the final turn. Do not exceed the maximum thread engagement depth of 0.563 inches.
- Q: My application has higher pressure. Can this probe be used?
- A: The standard rating is 500 psi. For higher pressures, you must contact the manufacturer’s custom design department for a modified version.
