Bently Nevada 3300 XL 8 mm Probe 330140-08-10-01-00 Industrial Monitoring

Description

Product Description

• Brand: Bently Nevada
• Model: 330140-08-10-01-00
• Series: 3300 XL 8 mm
• The probe gives high accuracy and strong durability for vibration sensing.
• The case length is 0.8 in and the cable is 1.0 m.
• TipLoc and CableLoc improve mechanical strength and field reliability.
• The PPS tip and stainless steel case resist heat and oil.

Technical Data

• Probe Type: Proximity probe with armored cable
• Measurement:
  • ISF: 7.87 V/mm ±5% (5 m, 1 m)
  • ISF for 9 m: ±6.5%
  • Linear range: 80 mil
  • DSL: ±1 mil (5 m, 1 m); ±1.5 mil (9 m)
• Electrical:
  • Probe DC resistance: 7.59 ±0.50 Ω (1.0 m)
  • Connector: Miniature coaxial ClickLoc
• Materials:
  • Probe tip: PPS
  • Probe case: AISI 303 or 304 stainless steel
  • Seal: Viton O-ring
• Environmental:
  • Operating temp: −52°C to +177°C (standard)
  • Extended tip temp: up to +218°C
  • Extended cable temp: up to +260°C
  • Humidity effect: <3% ASF change at 93% RH
• Mechanical:
  • Case length: 0.8 in
  • Cable length: 1.0 m
  • Pull strength: 330 N
  • Weight: 323 g/m
• Compatibility: Works with Bently Nevada 3300 XL systems and standard drivers.
• Agency Option: 00 (No approval required)

Installation Guide

• Keep the probe away from strong electromagnetic noise.
• Set the gap inside the linear region.
• Route the cable to avoid sharp bends and pinch points.
• Use ClickLoc to secure the connector firmly.

Commissioning and Maintenance

• Check DC resistance before system power-up.
• Verify linearity with standard test tools.
• Inspect cable armor at high vibration points.
• Keep the probe tip clean for stable readings.

Typical Applications

• Steam and gas turbines
• Compressors and expanders
• Pumps and motors
• Critical-speed vibration studies
• Machine protection systems

Diagnostic Capabilities

• Detect shaft displacement and runout.
• Support early bearing fault detection.
• Help identify rotor unbalance and misalignment.
• Enable orbit monitoring for safety.

Packaging List

• 1× Bently Nevada 330140-08-10-01-00 probe
• 1× armored cable assembly
• 1× connector protector
• 1× installation guide

Warranty

• 12-month warranty from delivery date
• Covers manufacturing defects only

Shipping Options

• FedEx International
• UPS Express
• DHL Worldwide

FAQ

• How can I confirm the probe works with my system?
  This probe fits standard 3300 XL drivers when cable length matches.
• What gap should I use?
  Place the gap near the center of the 80 mil linear range.
• What if readings drift?
  Check resistance, connector seating, and tip cleanliness.
• Can the probe handle oil exposure?
  The PPS tip resists oil; FluidLoc option reduces leak paths.
• How do I extend service life?
  Avoid cable stress and keep temperature within limits.
