Bently Nevada 3300 XL 8mm Probe 330102-00-40-05-01-05 | Shaft Vibration Monitoring

Description

Product Introduction

• Bently Nevada
  330102-00-40-05-01-05
  is a 3300 XL 8mm Proximity Probe.
• It measures shaft vibration and position with high stability.
• It suits turbines, compressors, pumps, and large motors.
• The probe supports harsh and hazardous environments.
• It works with 3300 XL Proximitor sensors and monitors.

Model Code Structure

• 330102-00-40-05-01-05
  • 330102
    • 3300 XL series
    • 8 mm proximity probe
    • 3/8-24 UNF threaded probe body
    • Armored cable design
  • 00
    • Unthreaded length equals 0.0 inch
  • 40
    • Overall probe case length equals 4.0 inches
  • 05
    • Total probe cable length equals 0.5 meter
    • Designed for matching 0.5 meter Proximitor sensor
  • 01
    • Miniature coaxial ClickLoc connector
    • Connector protector included
    • Standard industrial cable type
  • 05
    • CSA approval
    • ATEX approval
    • IECEx approval

Product Description

• The 3300 XL 8mm Probe uses eddy current sensing technology.
• It provides stable output over temperature and humidity changes.
• The armored cable improves mechanical and EMI resistance.
• The PPS probe tip ensures chemical and thermal durability.
• Stainless steel housing supports long-term industrial use.

Technical Specifications

• Brand
  • Bently Nevada
• Model
  • 330102-00-40-05-01-05
• Series
  • 3300 XL proximity sensing system
• Measurement Performance
  • Linear range from 0.25 to 2.3 mm
  • Usable span equals 2 mm total travel
  • Output range approximately -1 to -17 Vdc
  • Recommended radial gap equals -9 Vdc
• Electrical Characteristics
  • Nominal DC resistance equals 7.45 ohms
  • Tolerance within plus or minus 0.50 ohms
  • Strong noise immunity with shielded triad wiring
• Environmental Tolerance
  • Operating temperature from -52°C to +177°C
  • Extended tip rating up to +218°C
  • Humidity drift less than three percent
  • Viton O-ring pressure seal

Warranty and Logistics

• Standard warranty equals 12 months.
• Shipping via FedEx, UPS, or DHL.
