Description
Premium 8mm Industrial Vibration & Position Probe
Introducing the Bently Nevada 330140-08-05-01-05 3300 XL 8 mm proximity probe. It delivers reliable monitoring for critical machinery. The design features patented TipLoc and CableLoc technology. This ensures superior durability and connection integrity. The thicker 8mm probe body offers excellent protection against physical damage. It is ideal for predictive maintenance in demanding industrial environments.
Key Technical Specifications
- Brand & Model: Bently Nevada 330140-08-05-01-05
- Series & Type: 3300 XL 8mm Probe (Unarmored)
- Core Measurement: Shaft Vibration / Position (Displacement)
- ➤ Electrical Performance
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil) ±5%.
- Probe Resistance: 7.73 Ω ± 0.50 Ω (for 1.5m cable).
- Linear Range: Over 2.0 mm (80 mils).
- Linearity Error (DSL): Better than ±0.025 mm (±1 mil).
- ➤ Mechanical Construction
- Probe Diameter: Robust 8 mm design.
- Case Length: 0.8 inches (Option Code: 08).
- Cable Length: 0.5 meter (Option Code: 05).
- Tip Material: Molded PPS Plastic (Polyphenylene Sulfide).
- Case Material: AISI 303/304 Stainless Steel.
- Cable Pull Strength: 330 N (75 lbf) with CableLoc.
- ➤ Environmental Ratings
- Operating Temperature: -52°C to +177°C (-62°F to +350°F).
- Extended Range (ETR): Available for higher temperatures.
- Humidity Stability: Less than 3% signal change at 93% RH.
- Pressure Seal: Viton® O-ring for tip-to-case seal.
- ➤ Connectivity & Certification
- Connector: Miniature Coaxial ClickLoc (Option 01).
- Safety Approvals: CSA, ATEX, IECEx (Option 05).
- Optional Feature: FluidLoc cable to prevent fluid ingress.
Simple Installation & Wide Compatibility
- Directly compatible with Bently Nevada 3300 XL monitoring systems.
- Easy mounting in standard 8mm probe holes.
- Simple gap voltage setup using your existing driver.
- The rugged design minimizes risk during installation.
- Always perform a final system calibration check.
Low Maintenance & Diagnostic Features
- No routine maintenance is required for the probe itself.
- Periodically inspect the cable and connector for damage.
- Monitor vibration trends for early fault detection.
- A stable gap voltage indicates healthy probe operation.
- Check resistance to diagnose potential probe issues.
Frequently Asked Questions
- Why choose an 8mm probe over a 5mm one?
- The 8mm design has a thicker tip and stronger case. It is much more resistant to bumps and abuse in harsh plants.
- Does this model come with the oil-blocking cable?
- Not by default. You must specify the FluidLoc cable option at the time of ordering to get that feature.
- What do the numbers in the part number mean?
- Each set of numbers is an option code. For example, “08” means 0.8″ case length, and “05” means 0.5m cable. This lets you customize your order.
- Can I replace a probe without recalibrating the whole system?
- Yes. The tight ±5% interchangeability tolerance often allows a direct swap. For critical applications, a verification check is still recommended.
- We have had cables vibrate loose. Is this a problem here?
- The patented CableLoc design specifically solves this. It mechanically locks the cable to withstand high vibration and 75 lbs of pull force.
- Is it suitable for high-temperature applications like steam turbines?
- The standard probe works up to 177°C (350°F). For hotter areas near steam lines, you need the Extended Temperature Range (ETR) version.
Shipping, Warranty & Application
- Packaging: Individual protective box with documentation.
- Warranty: Backed by a 12-month manufacturer warranty.
- Global Shipping: Fast delivery via FedEx, UPS, or DHL.
- Typical Use: Perfect for turbines, compressors, large motors, pumps, and fans to monitor vibration and prevent unexpected downtime.
