Description
Industrial-Strength Vibration Sensor
This is a heavy-duty sensor for demanding applications. The Bently Nevada 330101-00-59-10-01-05 is an 8mm 3300 XL 8mm Proximity Probe. It features patented designs for superior durability and pull strength. Use it to monitor critical turbines, compressors, and large pumps. It provides reliable data to prevent unexpected machine failure and downtime.
Complete Model Specification
- Basic Information
- Brand: Bently Nevada
- Part Number: 330101-00-59-10-01-05
- Product Line: 3300 XL 8 mm Probe
- Origin: Made in U.S.A.
- Part Number Configuration
- Series: 330101 (8mm, 3/8-24 UNF Thread)
- -00: Unthreaded Length = 0.0 in
- -59: Overall Case Length = 5.9 in
- -10: Total Cable Length = 1.0 m
- -01: Connector = ClickLoc with Protector
- -05: Approvals = CSA, ATEX, IECEx
- Series: 330101 (8mm, 3/8-24 UNF Thread)
Technical Performance Data
- Electrical Characteristics
- DC Resistance (1m): 7.59 Ω ± 0.50 Ω
- Linear Range: 2 mm (80 mils)
- Recommended Gap (Radial): -9 Vdc (~1.27 mm)
- Scale Factor (ISF): 7.87 V/mm ± 5-6.5%
- Linearity (DSL): < ±0.025 mm to ±0.038 mm
- Physical & Environmental
- Case Material: AISI 303/304 Stainless Steel
- Tip Material: Molded PPS (TipLoc™)
- Operating Temp: -52°C to +177°C (Std)
- Extended Temp: Tip to +218°C, Cable to +260°C
- Seal: Viton® O-ring (Pressure Differential)
- Weight: 323 g/m
- Robust Design Features
- Cable Strength (CableLoc™): 330 N (75 lbf) Pull
- FluidLoc™ Option: Prevents internal fluid leakage
- 8mm Advantage: Thicker coil encapsulation for ruggedness
- Installation Limits
- Max Torque: 33.9 N·m (Use 11.2 N·m recommended)
- Max Thread Engagement: 0.563 in
- Field Wiring: Up to 305 m (1000 ft) max
Expert FAQ for Engineers
What makes this “XL” series probe more robust?
It uses patented TipLoc™ molding for a stronger tip-body bond and CableLoc™ design for 330N cable pull strength. The 8mm diameter also provides a thicker protective casing around the coil.
When should I consider the optional FluidLoc™ cable?
Choose FluidLoc™ if your application involves oil or other liquids that could travel along the cable interior from inside the machine housing to the outside, posing a contamination or safety risk.
What do the CSA, ATEX, IECEx approvals mean for installation?
These are major international certifications for hazardous locations. This probe is approved for use in areas with potentially explosive atmospheres (gas, dust), which is common in oil & gas, chemical, and mining.
How does the 5.9-inch case length affect my mounting?
A longer case (5.9 in) is often needed to reach through thicker machine casings or mounting bosses. Verify the required “standoff” distance in your mechanical drawings to ensure proper tip-to-target gap.
What is included with my order and how is it shipped?
Your purchase includes the probe and a full 12-month manufacturer’s warranty. We ship globally using reliable express carriers: FedEx, UPS, and DHL. Tracking is provided for all shipments.
Need technical confirmation for your application?
Contact our engineering support via WhatsApp at +86 158 8020 0923 for assistance with model selection and compatibility checks.
