Bently Nevada 3300 XL Proximity Probes 330876-01-90-00-CN

Description

Bently Nevada 330876-01-90-00-CN – 3300 XL 50mm Proximity Probe (9m, CN-Approved)

Model Code Breakdown

330876-01-90-00-CN
├─ 330876 = 3300 XL 50mm probe base
├─ 01 = ½-20 English thread (straight exit)
├─ 90 = 9.0m (29.5ft) total length
├─ 00 = High-temp FluidLoc cable (no armor)
└─ CN = China-specific approvals

Technical Specifications

• Brand: Bently Nevada
• Model: 330876-01-90-00-CN
• Thread: ½-20 English (0.750in max engagement)
• Length: 9.0m (29.5ft) – for long-distance monitoring
• Resistance: 8.9Ω ±1.1Ω (9m cable) – stable signal over distance
• Material: AISI 304 SST case + PPS tip (heat/corrosion resistant)
• Temp Range: -35°C to +200°C (continuous) | +250°C (short-term, <24hrs)
• Cable: 75Ω triaxial PFA-insulated FluidLoc (prevents oil/water ingress)

Industrial Use Cases

• ???? Large Steam Turbines: Monitor DE end vibration from control rooms 29.5ft away – 9m cable reaches remote sensors.
• ⚡ Power Plant Boilers: Track valve alignment in high-heat zones (200°C) with dual seals blocking steam leaks.
• ????️ Refinery Piping: Detect pipe misalignment in humid, oily environments – FluidLoc cable resists moisture.

FAQ

Q: Can I use this with 5m Proximitor Sensors?
A: No – 9m probes require 9m sensors for accurate signal transmission.

Q: How to handle 250°C temps?
A: Safe for <24hrs; avoid prolonged use above 200°C to prevent PPS tip degradation.

Q: Does the cable need extra protection?
A: No – FluidLoc insulation blocks oil/water, but avoid sharp bends (minimum 25.4mm radius).

Q: Is this approved for China?
A: Yes – “CN” suffix means country-specific approvals are included.

Installation & Compatibility

Install using ½-20 English threads (0.750in max engagement). Works with 9m 3300 XL Proximitor Sensors. Removable cable collar helps route through tight spaces. Includes locknut with safety wire holes for secure mounting.

Package & Shipping

• 1x 330876-01-90-00-CN probe
• 9m FluidLoc cable
• Connector protectors

Warranty: 12 months factory coverage. Shipping: FedEx, UPS, DHL
