Description
Bently Nevada 330106-05-30-30-02-00 Long-Range Vibration Probe
Technical Specifications
| Parameter | Specification |
|---|---|
| Complete Model | 330106-05-30-30-02-00 |
| Cable Length | 3.0 meters (9.8 ft) |
| Electrical Resistance | 8.17Ω ±0.50 |
| Total Weight | 969g (34.2 oz) |
| Thread Size | M10×1 |
| Max Thread Depth | 15mm |
| Min Bend Radius | 35mm |
Model Suffix Breakdown
- 330106 – 8mm Reverse Mount Series
- 05 – Mounting Configuration
- 30 – Measurement Range
- 30 – 3.0 Meter Cable
- 02 – Miniature ClickLoc Connector
- 00 – No Special Certifications
Environmental Ratings
- Temperature Range:
- Probe Tip: -52°C to +218°C
- Cable/Connector: -51°C to +260°C
- Humidity Resistance: <3% ASF change at 93% RH (IEC 68-2-3)
- Sealing Technology: Viton® O-ring pressure seal
Installation Guide
- Max cable tension: 330N at probe case
- Critical cold limit: -34°C to prevent seal damage
- Recommended cable slack: 15-20% extra length
- Connector pull limit: 270N at cable junction
Shipping & Warranty
- 12-month manufacturer warranty
- Worldwide shipping via FedEx/UPS/DHL
- Express delivery: 2-4 business days
- Tracking included with all orders
Similar Models Comparison
| Model | Length | Connector | Certifications | Details |
|---|---|---|---|---|
| 330106-05-30-30-02-00 | 3.0m | ClickLoc | None | Current Model |
| 330106-05-30-05-02-CN | 0.5m | ClickLoc | Country Specific | Compact version |
| 330106-05-30-20-02-CN | 2.0m | ClickLoc | Country Specific | Mid-range version |
Technical FAQ
Q: What applications need 3-meter cables?
A: Ideal for large equipment like turbines, mills, and processing plants
Q: Can I use standard extension cables?
A: Yes, compatible with 75Ω triaxial monitoring systems
Q: Is this probe submersible?
A: Not recommended – choose FluidLoc models for wet environments
Q: Cable insulation options available?
A: Standard FEP or high-temp PFA versions
