Description
330106-05-30-30-12-CN | 3300 XL 8mm Reverse Mount Probe
Industrial-grade reverse mount vibration sensor for demanding environments. Made in USA with specialized FluidLoc® cable technology.
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 8mm (Full Code: 330106-05-30-30-12-CN)
- Resistance: 8.17Ω ±0.5Ω
- Temperature Range: -52°C to +177°C
- Cable Type: 75Ω triaxial FEP
- Weight: 323 g/m (11.4 oz/ft)
- Tensile Strength: 330N (75 lbf)
Installation Notes
- Max thread engagement: 15 mm
- Seal warning below -34°C (-30°F)
- Pressure testing available on request
Compatibility
Works with 3300 XL monitoring systems. FluidLoc® cable optional for most installations.
What’s Included
- Probe assembly
- Installation manual
Support & Delivery
12-month warranty. Ships via FedEx, UPS or DHL worldwide.
Common Questions
Q: When is FluidLoc® needed?
A: Only for direct fluid exposure – not required with probe sleeves
Q: Cable length options?
A: 0.5m to 9m standard, PFA option for +260°C
Q: Pressure rating?
A: Contact us for custom pressure testing
