Bently Nevada 330101-00-08-20-02-CN | Premium 3300 XL 8mm Vibration Probe

Description

High-Strength 8mm Vibration Probe

Meet the heavy-duty 3300 XL 8mm Proximity Probe. Its larger, rugged design resists physical damage. Patented features ensure reliable performance. This model is 330101-00-08-20-02-CN. It is built for tough industrial applications.

Understanding Your Model Code

• Your Complete Part: 330101-00-08-20-02-CN
• Core Product (330101):
  • 3300 XL 8 mm Probe.
  • 3/8-24 UNF Thread, No Armor.
  • Made in the USA.
• Your Configuration Details:
  • 00: Unthreaded Length = 0.0 in.
  • 08: Case Length = 0.8 in.
  • 20: Cable Length = 2.0 meters (6.6 ft).
  • 02: ClickLoc Coaxial Connector.
  • CN: Country-Specific Agency Approval.

Enhanced Design & Key Specs

• Patented Durability:
  • TipLoc: Stronger bond between tip and body.
  • CableLoc: Holds 330N (75 lbf) pull force.
• Optimal for Vibration:
  • Linear Range: 2.0 mm (80 mils).
  • Recommended Gap: 1.27 mm (50 mils) for -9 Vdc.
  • Sensitivity (ISF): 7.87 V/mm (200 mV/mil).
  • High Accuracy (DSL): Better than ±0.025 mm.
• Robust Construction:
  • Case: AISI 303/304 Stainless Steel.
  • Tip: Molded PPS Plastic.
• Installation Specs:
  • Torque (Full): 11.2 N•m (100 in-lbf).
  • Torque (First 3 Threads): 7.5 N•m (66 in-lbf).
  • Max Thread Engagement: 0.563 in.
• Environmental Ratings:
  • Standard Temp: -52°C to +177°C.
  • Extended Temp Option: Tip to +218°C.
  • Certified for Hazardous Areas (EPL Ga/Gc, Dc).

Expert Questions Answered

About Design & Selection

• Why choose an 8mm probe over a smaller one?
• The 8mm body is stronger. It has more material protecting the coil. This makes it perfect for environments with high vibration or risk of impact.
• What is the “FluidLoc” cable option mentioned?
• It’s a special cable option. It prevents oil or coolant inside a machine from leaking out through the cable’s core. Ask our team if you need it.

Technical Performance

• What does “Linear Range” mean for my measurements?
• It is the distance range where the voltage output is most accurate. For this probe, it’s from 0.25mm to 2.3mm from the target shaft.
• The specs mention “ISF” and “DSL”. Why are they important?
• ISF (Scale Factor) tells you how much voltage change per mil of movement. DSL (Linearity Error) tells you how straight and predictable that change is. Both are critical for accurate data.

Ordering & Support

• This probe is for a critical upgrade. What is your supply promise?
• We supply genuine Bently Nevada parts. The 330101-00-08-20-02-CN comes with a 12-month warranty. We ship globally via FedEx, UPS, and DHL for reliable delivery. For technical questions, message us: +86 158 8020 0923 (WhatsApp).
