Product Description
The Bently Nevada 3300 XL 8 mm Probe (Model: 330101-00-55-05-02-05) is a high-performance vibration monitoring sensor designed for industrial applications. Featuring a rugged 3/8-24 UNF thread and PPS plastic probe tip, it ensures durability in harsh environments. The CableLoc and TipLoc technologies provide superior pull strength (330 N) and tip bonding.
Technical Data
- Brand: Bently Nevada
- Model: 330101-00-55-05-02-05
- Suffix Breakdown: 00 (0.0″ unthreaded), 55 (5.5″ case), 05 (0.5m cable), 02 (Mini ClickLoc connector), 05 (CSA/ATEX/IECEx)
- Linear Range: 0.25–2.3 mm (10–90 mils)
- Accuracy (ISF): ±5% (5m system) / ±6.5% (9m system)
- Output Signal: -1 to -17 Vdc (7.87 V/mm scale)
- Temp Range: -52°C to +177°C (Standard), -52°C to +218°C (ETR)
- Pressure Seal: Viton® O-ring (not tested)
- Weight: 323 g/m (11.4 oz)
Installation Guide
- Max cable length: 305 meters (shielded triad cable recommended).
- Radial gap setting: -9 Vdc (~1.27 mm / 50 mils).
- Avoid temps below -34°C to prevent seal damage.
Compatibility
Works with 3300 XL Proximitor Sensors. Supports 0.2–1.5 mm² (16–24 AWG) wiring.
Certifications
- CSA, ATEX, IECEx approved.
Package & Warranty
- Includes probe
- 1-year warranty against defects.
Applications
- Gas turbines
- Steam turbines
- Pumps & compressors
