Bently Nevada 330101-00-67-20-02-00 | 6.7 Inch Case 3300 XL 8mm Probe | Deep Mount Sensor

Description

Product Description: Long-Reach Vibration Probe

This is a Bently Nevada 3300 XL 8mm Probe with a long 6.7-inch case. It is perfect for deep mounting applications. The probe gives accurate vibration and position data. It helps protect your expensive machinery from unexpected failure.

Product Configuration: Understand Your Part Number

The part number tells you exactly what you are getting.

• Basic Model: 330101 (8 mm Probe, 3/8-24 UNF, no armor)
• Your Specific Model: 330101-00-67-20-02-00
  • › 00 – Unthreaded Length: 0.0 inch
  • › 67 – Case Length: 6.7 inch (Long reach)
  • › 20 – Cable Length: 2.0 meters / 6.6 feet
  • › 02 – Connector: Miniature Coaxial ClickLoc
  • › 00 – Special Option: None

Technical Data & Specifications

• Electrical & Measurement
  • › Linear Range: 2.0 mm (80 mils)
  • › Sensitivity: 7.87 V/mm (200 mV/mil)
  • › Probe Resistance (2.0m): 7.88 Ω ±0.50 Ω
  • › Best Gap: Set to -9 Vdc (~1.27 mm / 50 mils)
• Mechanical Build
  • › Case Material: Stainless Steel (303/304)
  • › Tip Material: Rugged PPS Plastic
  • › Thread: 3/8-24 UNF
  • › Cable Strength: 330 N pull-off force (CableLoc)
  • › Total Case Length: 6.7 inches
• Environmental Ratings
  • › Temperature: -52°C to +177°C (-62°F to +350°F)
  • › Humidity: Stable performance up to 93% RH
  • › Pressure Seal: Viton® O-ring (differential pressure)

Why Choose This Probe?

• Extra-Long Case: The 6.7-inch length is ideal for deep mounting holes.
• Super Strong: 8mm diameter and TipLoc design fight physical damage.
• Secure Cable: CableLoc holds the cable tight, even with strong pulls.
• Ready to Use: Comes with a 2-meter cable and ClickLoc connector.
• Industry Standard: Trusted for critical machinery protection worldwide.

Installation Notes

• This probe fits deep mounting holes.
• Use the 3/8-24 UNF thread to install it.
• Set the gap between the tip and machine shaft.
• Connect the ClickLoc connector firmly.
• Use proper shielded wiring for the best signal.

Typical Uses

• Vibration monitoring on large turbines and gearboxes.
• Machinery with deep bearing housings.
• Shaft position measurement in pumps and compressors.
• Any application needing a long-case probe.

Expert FAQs

When should I choose this 6.7-inch case probe?

Choose this model when your mounting hole is deep. A standard 2-inch probe may not reach. This long probe ensures the tip is at the correct measurement position.

Can I cut or shorten the probe cable?

No. Never cut the integral probe cable. The electrical calibration is set for the 2.0m length. Use proper extension cables if you need more distance.

Does the long case affect performance?

No. The case length does not change electrical performance. The measurement comes from the tip. The long case just allows installation in deeper locations.

Is this compatible with older Bently Nevada monitors?

Yes. The 330101-00-67-20-02-00 works with 3300 XL systems. It also works with older 3300 monitors that use an 8mm probe. Check your system manual.

What if I need a metric thread probe?

For M10 metric threads, please see our selection of 3300 NSv Probes. They offer similar performance with metric fittings.

Ordering & Support Details

• Package: One probe, ready to install.
• Warranty: Full 12-month warranty against defects.
• Shipping: Fast worldwide delivery via FedEx, UPS, DHL.
• Questions? Contact us on WhatsApp for support.
