Description
Industrial-Grade 8mm Vibration Probe
This is the Bently Nevada 330101-00-77-15-12-05. It is a premium 3300 XL 8mm Proximity Probe. Features a long 7.7-inch case and fluid-blocking cable. Built in the USA for extreme reliability in monitoring turbines, compressors, and critical pumps.
Product Feature Map
- Base Model: 330101 (3/8-24 UNF Thread)
- → Option 00: Unthreaded Length = 0.0 in
- → Option 77: Case Length = 7.7 in
- → Option 15: Cable Length = 1.5 m
- → Option 12: Connector = ClickLoc with FluidLoc Cable
- → Option 05: Approvals = CSA, ATEX, IECEx
Core Performance & Specifications
- Thread Size: 3/8-24 UNF.
- Case: Stainless Steel (AISI 303/304).
- Tip: Durable PPS Plastic with patented TipLoc.
- Cable: FluidLoc design prevents internal oil leakage.
- Resistance: 7.73 Ω ± 0.5 (for 1.5m cable).
- Linear Range: 2.0 mm (80 mils).
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil).
- Accuracy (DSL): Better than ±0.025 mm (±1 mil).
- Temperature: -52°C to +177°C Standard Range.
- Seal: Viton O-ring for pressure differential.
- Cable Strength: Patented CableLoc, 330 N pull strength.
Package & Support Information
- One Bently Nevada 330101-00-77-15-12-05 probe.
- Ready for immediate installation.
- Full 12-month manufacturer’s warranty.
Fast worldwide delivery via FedEx, UPS, or DHL. For technical support, contact us on WhatsApp at +86 158 8020 0923.
FAQ: Installation & Selection
What is the FluidLoc cable feature?
It is a special cable option. It stops oil or other machine fluids from traveling inside the cable to the connector, preventing leaks at the panel.
Why is a 7.7-inch case beneficial?
The long case (option -77) is for deep mounting applications. It allows the probe to reach through thick machinery walls or insulation layers.
What is the recommended gap voltage?
For radial vibration measurement, set the gap to achieve -9 Vdc. This is approximately 1.27 mm (50 mils) from the target shaft.
Can this probe handle high humidity?
Yes. It shows less than 3% change in performance after 56 days at 93% relative humidity, meeting IEC standards.
How do I choose between standard and extended temperature probes?
For most applications below 177°C, this standard 330101 model is perfect. For hotter environments up to 218°C, inquire about the Extended Temperature Range (ETR) version.
