Bently Nevada 330102-00-28-05-02-00 8mm Proximity Probe – 3300 XL Series

Description

Bently Nevada 330102-00-28-05-02-00 | 3300 XL 8 mm Proximity Probe

This probe is used for vibration and position measurement.
It is built for harsh industrial machines.
It offers stable and repeatable signals.

Model Structure Breakdown

• 330102
  • 3300 XL 8 mm proximity probe
  • 3/8-24 UNF threaded case
  • Armored probe design
• 00
  • Unthreaded length: 0 in
• 28
  • Case length: 2.8 in
• 05
  • Total cable length: 0.5 m
• 02
  • Miniature coaxial ClickLoc connector
  • Standard probe cable
• 00
  • No agency approval required

Key Electrical Characteristics

• Nominal DC resistance: 7.45 Ω
• Resistance tolerance: ±0.50 Ω
• Stable output with low signal drift
• Designed for short probe length accuracy

Measurement Performance

• Linear range from 0.25 to 2.3 mm
• Total linear span: 2 mm
• Recommended vibration gap: -9 Vdc
• Typical gap distance: 1.27 mm

Mechanical Construction

• Probe tip material: PPS
• Probe case material: Stainless steel
• Thread size: 3/8-24 UNF
• Max thread engagement: 0.563 in
• Weight: 323 g per meter

Environmental Limits

• Standard temperature: -52 to +177 °C
• Extended tip temperature up to +218 °C
• Cable temperature up to +260 °C
• Humidity change less than 3%

Installation and Compatibility

• Designed for matching 0.5 m Proximitor sensor
• Not compatible with 3 m Proximitor systems
• Supports field wiring up to 305 m
• Recommended shielded triad cable

Product Advantages

• High stability in vibration monitoring
• Durable armored probe body
• Reliable sealing with Viton O-ring
• Proven long service life
• Suitable for critical rotating assets

Hazardous Area Suitability

• Supports intrinsic safety installations
• Zone 0 and Zone 2 capable
• Compatible with zener barriers
• Compatible with galvanic isolators

Warranty and Shipping

• Standard warranty: 12 months
• Fast global shipping available
• Delivery via FedEx
• Delivery via UPS
• Delivery via DHL

Professional FAQ

• Can this probe be used with longer Proximitor cables?
• No. It is matched to 0.5 m systems only.
• Is pressure testing done before shipment?
• No. Testing is available on request.
• What machines commonly use this probe?
• Compressors, turbines, and large motors.
• Does armored design improve reliability?
• Yes. It protects against vibration damage.
• How do I select the correct probe length?
• Match probe and Proximitor lengths exactly.

Contact for Selection Support

• WhatsApp: +86 158 8020 0923
