Description
Compact Armored Vibration Probe with Connection Guard
This Bently Nevada 3300 XL 8mm Probes combines protection with a short form factor. Its armored cable and connector protector defend against physical damage. The compact 30mm case fits space-limited applications. It delivers reliable sensing where durability is key.
Standout Product Features
- Dual Physical Protection: Armored cable resists crushing. Connector protector guards against impacts and strain.
- Compact Installation: Short 30mm case length suits tight spaces. Ideal for machinery with limited mounting depth.
- Standard Meter System: 1.0-meter cable works with common 1m Proximitor sensors. Ensures broad compatibility.
- Robust 8mm Construction: Stainless steel case and armored jacket. Provides maximum durability in tough conditions.
- Hazardous Area Rated: Compliant with ia, nA, and ec protection concepts. Safe for use in classified zones.
Part Number Configuration
Your Specific Model: 330104-00-03-10-01-00
- ■ 330104 – Core: 3300 XL 8mm, M10x1, With Armor
- │ 00 – Unthreaded Portion
- Length: 0 mm
- │ 03 – Casing Length
- Length: 30 mm
- │ 10 – Total Cable
- Length: 1.0 m (3.3 ft)
- │ 01 – Connector & Guard
- Type: ClickLoc with Protector, Standard Cable
- └ 00 – Approval Status
- Option: Not Required
- │ 00 – Unthreaded Portion
Essential Technical Data
- Electrical Specifications:
- Probe Resistance (1.0m): 7.59 Ω ± 0.50 Ω
- System Sensitivity: 200 mV/mil (7.87 V/mm)
- Linear Range: 2.0 mm (80 mils)
- Recommended Gap: 1.27 mm (50 mils) for -9 Vdc
- Mechanical Properties:
- Mounting Thread: M10 x 1.0 Metric
- Thread Engagement Limit: 15 mm
- Construction: Armored Cable, SST Case, PPS Tip
- Seal: Viton O-Ring
- Weight: 323 g/m
- Environmental Ratings:
- Operating Temperature: -52°C to +177°C
- Extended Capability: Tip up to +218°C
- Humidity Immunity: < 3% signal drift in 93% RH
- Safety Standards: AEx/Ex ia, nA, ec IIC T5…T1
Simple Setup Instructions
Mount the short probe using the M10x1 thread. Ensure the armored cable is clamped securely along its route. Connect the protected ClickLoc connector. For installation advice, message our team on WhatsApp: +86 158 8020 0923.
What’s in the Box & Support
- One Bently Nevada 330104-00-03-10-01-00 armored probe assembly.
- 1.0-meter armored cable with ClickLoc connector and protector.
Shipping Options: Dispatched via FedEx, UPS, or DHL for timely delivery.
Quality Guarantee: Backed by a 12-month manufacturer’s warranty.
Frequently Asked Questions
What is the benefit of a 30mm case (option 03)?
This very short case length is used when the probe mounts directly onto a thin machine wall or bracket with minimal clearance behind it. It’s a space-saving design.
Does the armored cable affect flexibility?
Yes, the armor adds stiffness. While it offers great protection, the cable has a larger minimum bend radius. Plan your routing path accordingly to avoid sharp turns.
Is this probe suitable for Zone 0 hazardous areas?
Yes, when installed with the correct intrinsically safe barriers per drawing 141092, this 330104-00-03-10-01-00 probe can be used in Zone 0 (AEx/Ex ia IIC).
How do I handle warranty service for this item?
Contact us within the 12-month period with your order details if you suspect a defect. We will coordinate the warranty process directly with the manufacturer for you.
What is a pro tip for installing in tight spaces?
Connect the ClickLoc connector to the monitor before finally tightening the probe into its threaded hole. This avoids straining the cable or connector in confined areas.
Can I use this 1m armored probe with a 5m or 9m system?
No. This probe has a 1.0m cable (suffix -10). It is calibrated for use with a 1-meter Proximitor sensor. Mixing system lengths causes measurement inaccuracy.
