Description
Armored & Protected Machine Health Probe
Introducing the Bently Nevada 330104-00-05-05-11-05. This premium 3300 XL 8mm Proximity Probe comes with armored casing and FluidLoc cable. Designed for harsh environments where cable damage or fluid ingress is a risk. A robust solution for reliable monitoring.
Part Number Configuration Guide
- Model: 330104-00-05-05-11-05
- • Code 00: 0mm Unthreaded Length.
- • Code 05: 50mm Overall Case Length.
- • Code 05: 0.5 Meter Cable Length.
- • Code 11: ClickLoc Connector with Protector & FluidLoc Cable.
- • Code 05: CSA, ATEX, IECEx Approvals.
Technical Specifications & Features
- Key Feature: Armored Probe Body (Model 330104).
- Thread: M10 x 1.0 mm Metric.
- Construction: Stainless Steel Case, PPS Tip.
- Cable: FluidLoc design prevents internal fluid wicking.
- Protection: Connector protector included.
- Electrical: 7.45 Ω ± 0.5 Resistance (0.5m cable).
- Performance: 2.0 mm Linear Range, 7.87 V/mm Sensitivity.
- Environment: -52°C to +177°C Operating Range.
- Sealing: Viton O-Ring for pressure differential.
- Safety: Certified for Class I, Zone 0/1/2 areas.
What You Receive & Support
- One Bently Nevada 330104-00-05-05-11-05 armored probe.
- With connector protector installed.
- Complete documentation.
- 12-month manufacturer’s warranty for peace of mind.
Fast global shipping with FedEx, UPS, or DHL. For configuration help: WhatsApp us at +86 158 8020 0923.
FAQ: Armored Probe Specifics
What is the “armor” on this probe?
The armor is a robust, additional metal sheath over the standard probe body (model 330104 vs. 330103). It provides extra physical protection against impact and abrasion.
When should I choose the armored version?
Choose this 330104 model in high-risk areas. Examples include near moving parts, in crowded cable trays, or where tools might drop.
What is the connector protector?
It is a protective boot (code -11). It shields the ClickLoc connector from dust, moisture, and physical damage before and after installation.
Is the 0.5m cable length sufficient?
The 0.5m cable is ideal for short runs. It is often used when the probe connects directly to a nearby junction box or extension cable.
Can I get a longer armored cable?
The armored feature is on the probe body. The cable itself is a standard FluidLoc type. For longer runs, you would typically add a separate extension cable. Contact us to discuss your 330104 system setup.
