Description
Heavy-Duty Industrial Sensor for Critical Assets
Meet the Bently Nevada 330104-05-13-10-02-00, an armored 8mm proximity probe designed for maximum protection. This metric-thread sensor is built to monitor vibration in the toughest environments, from offshore platforms to chemical plants. It combines robust construction with precise measurement.
Why Choose This Probe?
- Armored for Extreme Duty: Stainless steel armor protects the probe body from physical impact and abrasion.
- Global Metric Standard: Features an M10 x 1 thread for easy integration with international machinery designs.
- Intrinsically Safe Options: Approved for use in hazardous areas (Class I, Zone 0/1/2) with proper barriers.
- Optimal Cable Length: 1.0-meter attached cable offers great flexibility for common installation layouts.
- Engineered to Last: Patented TipLoc and CableLoc ensure a durable, reliable connection that resists vibration.
Your Part Number Decoded
The code 330104-05-13-10-02-00 breaks down into these key features:
- Series & Core: 330104 – 3300 XL 8mm Probe, M10x1 Thread, With Armor
- Suffix -05: Unthreaded Length = 50 mm
- Suffix -13: Overall Case Length = 130 mm
- Suffix -10: Cable Length = 1.0 Meter (3.3 ft)
- Suffix -02: Connector = Miniature ClickLoc Coaxial
- Suffix -00: Agency Approval = Standard
Complete Specification Details
- Brand & Model: Bently Nevada 330104-05-13-10-02-00
- Type: 3300 XL 8mm Armored Proximity Probe (Metric)
- Electrical:
- Linear Range: 2.0 mm (80 mils)
- Gap Setting: -9 Vdc (~1.27 mm)
- Probe Resistance (1.0m): 7.59 Ω ± 0.50 Ω
- Mechanical:
- Thread: M10 x 1.0
- Max Thread Engagement: 15 mm
- Case Torque (Rec./Max.): 11.2 N•m / 33.9 N•m
- Case Material: AISI 303/304 Stainless Steel with Armor
- Tip Material: PPS Plastic
- Environmental:
- Operating Temp: -52°C to +177°C (Standard)
- Hazardous Area: Class I, Zone 0/1/2 compliant (with proper system)
- Humidity: < 3% signal change at 93% RH
- Seal: Viton O-ring for pressure differential
Installation & System Notes
- Mount in an M10x1 tapped hole. Do not exceed 15mm thread engagement.
- Use a torque wrench. Tighten to the recommended 11.2 N•m (100 in•lbf).
- For hazardous areas, ensure your full system (barrier/isolator) is certified.
- This probe is compatible with standard 3300 NSv Probes extension cables.
What’s Included & Support
- Package: One armored probe with 1.0m cable and ClickLoc connector.
- Warranty: Full 12-month coverage for peace of mind.
- Global Logistics: Reliable express shipping via FedEx, UPS, and DHL.
Expert FAQ
Mechanical & Application
- What is the main benefit of the armored version?
- The armor provides an extra layer of stainless steel protection. It guards against physical damage from tools, debris, or accidental impact in harsh industrial settings.
- Can I use this M10x1 probe in a 3/8-24 UNF hole?
- No. The M10x1 metric thread and 3/8-24 UNF imperial thread are not compatible. You must have the correctly tapped mounting hole for your probe thread type.
Hazardous Area Use
- Is the probe itself certified for hazardous areas?
- The probe has relevant approvals (ia, nA, ec), but it must be used as part of a certified system with the correct intrinsic safety barriers or galvanic isolators per Bently Nevada drawings.
- What does the “Temperature Schedule” mean for my application?
- It defines the safe ambient temperature range based on your required Temperature Classification (T1-T5). You must select a probe system rating suitable for your area’s maximum ambient temperature.
Purchasing & Delivery
- I need this for a project in a remote location. Can you ship there?
- Yes. We ship the 330104-05-13-10-02-00 globally via major carriers (FedEx/UPS/DHL) to most industrial sites. Contact us with your destination for a shipping quote and timeline.
