Bently Nevada 330104-15-23-10-02-00 Probe | Armored 3300 XL 8mm Sensor

Description

Armored Metric Proximity Probe

This is the Bently Nevada 3300 XL 8 mm Probe with armor. Model 330104-15-23-10-02-00 features a sturdy M10x1 thread. It is built for demanding industrial environments. The armored design offers extra protection against physical damage.

Decoding Your Probe: 330104-15-23-10-02-00

This number defines your sensor’s exact build. Below is what each part means for you.

• 330104 – Armored 8mm Probe, M10x1 Thread
• Option -15
  • Unthreaded Length: 150 mm
• Option -23
  • Overall Case Length: 230 mm
• Option -10
  • Total Cable Length: 1.0 meter
• Option -02
  • Connector: Miniature ClickLoc Coaxial
• Option -00
  • Agency Approval: Not Required

Core Technical Specifications

• Type: 3300 XL 8 mm Proximity Probe, Metric.
• Thread: M10 x 1.0 mm.
• Max Engagement: 15 mm.
• Torque: Recommended 11.2 N•m (100 in•lbf).
• Measurement Range: Linear up to 2 mm (80 mils).
• Set Point: Optimal gap at -9 Vdc (~1.27 mm).
• Probe Resistance (1.0m): 7.59 Ω ± 0.50.
• Materials: PPS Plastic Tip, 303/304 Stainless Steel Case.
• Seal: Viton® O-ring for pressure differentials.
• Temperature: Standard range -52°C to +177°C.

Safety & Agency Approvals

This probe supports safe use in hazardous areas. It works with approved barriers or isolators.

• Intrinsic Safety (ia): For Zone 0 with proper barriers.
• Non-Incendive (nA, ec): For Zone 2 / Division 2 areas.
• See the temperature schedule for specific T-ratings.

Simple Installation Steps

1. Screw the probe into the M10 x 1 threaded hole.
2. Do not exceed the recommended installation torque.
3. Connect the ClickLoc connector until it clicks.
4. Set the gap to achieve -9 Vdc output for vibration.
5. Use shielded, 3-conductor cable for field wiring.

What You Receive & Support

• One (1) Bently Nevada 3300 XL 8mm Armored Probe.
• Full part number: 330104-15-23-10-02-00.
• Full Warranty: Protected by a 12-month guarantee.
• Fast Shipping: Dispatched via FedEx, UPS, or DHL.

Ideal Applications

Perfect for heavy machinery with metric fittings. Use on turbines, compressors, and large motors in hazardous (Classified) areas. For non-armored metric probes, see our 3300 NSv Probes collection.

Expert FAQ & Selection Guide

Technical Specifications

• What is the “armor” on this probe model?
• The armor is a thicker, reinforced stainless steel case. It protects the probe from impact and stress in rough installations.
• How do I know if my area needs an “ia” or “nA” rated probe?
• Your plant’s safety document (HAZOP) will specify the zone. “ia” is for the most hazardous Zone 0. “nA” is for less hazardous Zone 2. Always consult a safety engineer.

Installation & Usage Advice

• Why is there a maximum thread engagement of 15 mm?
• This ensures the probe’s sealing O-ring sits correctly. Engaging more than 15mm may prevent a proper seal, allowing oil ingress.
• Can I use this probe outdoors in all weather?
• Yes. Its materials and seal resist humidity and wide temperatures. For constant saltwater spray, discuss your application with us first.

Ordering & Service Guide

• What support comes with my order of 330104-15-23-10-02-00?
• You get the genuine probe, a 12-month warranty, and reliable FedEx/UPS/DHL shipping. Need help installing? Contact our technical team on WhatsApp.
