Description
Bently Nevada 3300 XL Proximitor Sensor
Made in the U.S.A., the 3300 XL Proximitor Sensor 330180-50-05 offers advanced performance with CSA, ATEX, and IECEx certifications for hazardous environments. Designed for high-density DIN-rail or panel mounting, it features RFI/EMI immunity, eliminating the need for shielded conduit. The SpringLoc terminal strips ensure fast, secure wiring, reducing installation time and complexity.
Technical Specifications
| Parameter | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 330180-50-05 |
| Suffix Codes | 50: 5.0 m System Length, Panel Mount 05: CSA/ATEX/IECEx Approvals |
| Input Compatibility | 3300-series 5 mm & 3300 XL 8 mm Probes |
| Power Requirements | -17.5 Vdc to -26 Vdc (12 mA max) |
| Output Resistance | 50 Ω |
| Material | A308 Aluminum Housing |
| Connector Material | Gold-plated Brass/Beryllium Copper |
| Weight | 246 g (8.67 oz) |
| Temperature Range | Operating: -52°C to +100°C Storage: -52°C to +105°C |
| Supply Sensitivity | < 2 mV/V |
Contact Us: For technical support or customization, email sales@ubestplc.com.
