Description
Bently Nevada 330505-02-02-06 Vibration Sensor – Heavy-Duty Industrial Monitor
New factory-sealed sensor with 5/8-18 UNF adapter for large equipment. Ideal for turbines, generators, and heavy machinery. Detects vibration problems before failure.
Model Breakdown
| Suffix | Feature | Specification |
|---|---|---|
| 02 | Mounting Angle | 90° ±5° |
| 02 | Internal Thread | 3/8-24 UNF-2B |
| 06 | Adapter Size | 5/8-18 UNF |
Technical Performance
- Frequency range: 0.5-1000 Hz
- Accuracy: ±0.9dB (60-12,000 CPM)
- Velocity capacity: 4 in/s peak
- Output: 20 mV/mm/s ±10%
- Cable length: 1000 ft max
Rugged Construction
- Material: 300 series stainless steel
- Sealing: Hermetic – 100% humidity safe
- Temp range: -40°F to 212°F
- Shock rating: 100g survivability
- Weight: Only 13.2 oz
Installation Guide
- Adapter: 5/8-18 UNF
- Max torque: 40 in-lb
- Pin A positive for upward movement
- Works with 3500/46M monitoring systems
Package & Support
- New in original factory packaging
- 12-month manufacturer warranty
- Global shipping: FedEx, UPS, DHL
- No calibration documents included
Common Questions
Q: Why 5/8-18 UNF adapter?
A: For heavy equipment requiring larger mounting points
Q: Minimum vibration detected?
A: As low as 0.5 Hz – perfect for slow-rotating machines
Q: Works in cold environments?
A: Yes, down to -40°F
