Description
Bently Nevada Compact Proximity Sensor
Product Identification
- Part Number: 330701-01-20-10-02-00
- Model: 3300 XL 11 mm Probe
- Made in USA (COO available)
- Warranty: 12 months
Configuration Breakdown
- 330701 – 1/2-20 UNF thread model
- 01 – Unthreaded length: 1.0 inch
- 20 – Case length: 2.0 inches
- 10 – Cable length: 1.0 meter
- 02 – Standard ClickLoc connector
- 00 – No agency approvals
Technical Specifications
| Thread Type | 1/2-20 UNF |
| Thread Engagement | Max 0.750 inch |
| Electrical Resistance | 5.9 ± 0.5 Ω |
| Installation Torque | 15.2 N•m (133 in•lb) |
| Temperature Range | -51°C to +177°C |
| Bend Radius | 25.4 mm minimum |
Design Features
- 1.0 inch unthreaded section
- PPS polymer sensing tip
- Viton O-ring pressure seal
- Stainless steel construction
- Compact 2.0 inch case
Installation Guide
- Hand tighten plus 1/4 turn
- Max thread engagement: 0.750 inch
- Minimum bend radius: 25.4 mm
- Do not install below -34°C
Shipping & Support
- Weight: 0.17 kg
- Delivery: FedEx / UPS / DHL
- Warranty: 12 months
- Condition: Factory sealed
Frequently Asked Questions
Q: What does 1/2-20 UNF mean?
A: Standard thread size (1/2 inch diameter, 20 threads per inch)
Q: How long is the unthreaded section?
A: 1.0 inch smooth body
Q: Minimum temperature during use?
A: -34°C to protect seals
Q: Cable type?
A: 75Ω triaxial FEP insulated
Q: Thread depth limit?
A: Maximum 0.750 inch engagement
