Product Spotlight
Introducing the genuine Bently Nevada 3300 XL 11 mm Proximity Probe, part number 330702-00-26-10-01-05. This armored sensor is made in the USA, designed for robust vibration monitoring. Ships new in factory packaging with a 12-month warranty. We offer reliable delivery via FedEx, UPS, and DHL.
For technical inquiries, reach us on WhatsApp at +86 158 8020 0923.
Detailed Specifications
- Product Profile
- Manufacturer: Bently Nevada
- Full Part No.: 330702-00-26-10-01-05
- Series & Type: 3300 XL Series, 11mm Proximity Probe
- Key Feature: Armored Construction
- Origin: U.S.A.
- Understanding Your Part Number
- Base Identifier (330702): 11mm Probe, 1/2-20 UNF Thread, With Armor.
- Feature Breakdown:
- -00: Unthreaded Shank = 0.0 in
- -26: Overall Case = 2.6 in
- -10: Attached Cable = 1.0 meter (3.3 ft)
- -01: Connection = ClickLoc with protector, standard cable
- -05: Compliance = Multiple International Approvals
- Technical Attributes
- Electrical Spec: DC Resistance (1.0m): 5.9 Ω (±0.5 Ω).
- Physical Build:
- Mounting: 1/2-20 UNF Thread.
- Max Engagement: 0.750 inches.
- Installation Torque: Recommended 15.2 N·m.
- Connector Torque: Hand tight only.
- Cable Bend Radius: Minimum 25.4 mm.
- Construction Materials:
- Sensing Tip: PPS (Polyphenylene sulfide).
- Body: AISI 304 Stainless Steel (Armored).
- Cable: 75 Ω triaxial with FEP insulation.
- Operating Conditions:
- Temperature Range: -51°C to +177°C.
- Warning: Avoid sustained temperatures below -34°C.
- Certifications: Meets multiple agency standards (option 05).
- Hazardous Area Ratings: Suitable for defined EPL Ga/Gc/Dc temperature classes.
Professional FAQs & Selection Help
Technical Clarifications
- What is the main use case for a 1-meter cable length?
The 1-meter length is ideal for installations where the monitor or junction box is very close to the measurement point. It minimizes excess cable in control panels.
- Does “Multiple Approvals (05)” mean it’s certified for explosive areas?
Option 05 indicates general international safety approvals. However, for specific use in classified hazardous (Ex) areas, you must verify the exact certifications match your site’s required standards.
Installation & Compatibility
- Is this armored probe much heavier or harder to install?
No. The armor adds minimal weight (0.17 kg). Installation torque remains the same. The armor is a protective sleeve that does not complicate standard mounting procedures.
- Can I use this 1-meter probe with a 5-meter extension cable?
Yes, but you must use a compatible, calibrated extension cable and connector from the Bently Nevada system. The total electrical length must match your monitor’s configuration.
Purchasing & Support
- What is your process if the probe is damaged during shipping?
Inspect the package upon delivery. If damage is found, contact us immediately with photos. The 12-month warranty covers defects, and we will assist with carriers like FedEx/UPS/DHL for any shipping-related claims.
