Description
Long-Reach Armored Probe for Distant Monitoring
Introducing the Bently Nevada 330702-00-26-90-02-00. This is a heavy-duty 11 mm Proximity Probe with a full 9-meter armored cable. Perfect for installations where the monitoring panel is far from the machine. It is new, original, made in the USA, and backed by a 12-month warranty.
Understanding Your Part Number
Complete Model: 330702-00-26-90-02-00
- ► 330702 — Base: 11mm Probe, 1/2-20 UNF Thread, With Armor
- • 00 — Unthreaded Length: 0.0 in
- • 26 — Case Length: 2.6 in
- » 90 — Cable Length: 9.0 meters
- » 02 — Connector: ClickLoc, Standard Cable
- › 00 — Agency Approval: Not Required
Core Technical Data
- General Information
- Manufacturer: Bently Nevada
- Product Type: 3300 XL 11mm Proximity Probe
- Origin: Made in USA
- Electrical & Dimensional Specs
- Probe Resistance (9m): 8.5 Ω ± 1.1 Ω
- Cable: 75 Ω Triaxial, FEP, with Stainless Steel Armor
- Thread: 1/2-20 UNF (Max Engagement: 0.750 in)
- Case Length: 2.6 inches
- Tip Material: PPS; Case Material: AISI 304 SST
- Installation & Limits
- Mounting Torque: 15.2 N•m Recommended
- Operating Temperature: -51°C to +177°C
- Min Cable Bend Radius: 25.4 mm (1.0 in)
- Connector Torque: Finger Tight Only
Package & Warranty Information
- One (1) 330702-00-26-90-02-00 Probe Assembly
- Factory-fresh in original packaging
- Full 12-Month Original Manufacturer Warranty
Shipping Service
We ship globally using express services. Choose from FedEx, UPS, or DHL for reliable and tracked delivery to your site.
FAQ: Your Questions Answered
About This Specific Model
- Why is the resistance higher for this 9-meter probe?
- Longer cables have naturally higher resistance. The specified 8.5 Ω is normal for a 9m system and is pre-calibrated in compatible monitors.
- What are typical uses for a 9-meter cable?
- It’s ideal for large machinery or when the monitoring rack is located in a remote cabinet, allowing flexible routing over long distances.
Installation & Application
- How do I handle and route such a long armored cable?
- Always respect the 25.4 mm minimum bend radius. Use cable ties loosely. Avoid sharp bends or kinks to prevent damage to the armor and inner conductors.
- Can I cut the cable to a shorter length if needed?
- No. The probe and cable are a calibrated unit. Cutting the cable will change its electrical characteristics and void the warranty. Order the correct length.
Purchasing & Support
- I need a long cable but a different connector. Is that possible?
- Yes, Bently Nevada offers various configurations. To explore options or get a quote for a custom variant, please reach out to our team via WhatsApp at +86 158 8020 0923 for personalized service.
