Bently Nevada 330703-000-100-10-02-05 Vibration Probe | 3300 XL Series

Description

Product Overview

Get the genuine Bently Nevada 3300 XL 11 mm Proximity Probe, part number 330703-000-100-10-02-05. This is a new, factory-sealed sensor for accurate machinery monitoring. It comes with a full 12-month warranty. We ship worldwide via FedEx, UPS, and DHL.

Key Product Details

• Core Product Info
  • Brand: Bently Nevada
  • Model & Series: 330703 (3300 XL Series)
  • Type: 11mm Eddy Current Proximity Probe
  • Condition: New, Original
  • Warranty: 12 Months
• Part Number Breakdown
  • Base Model: 330703
    • 3300 XL 11 mm Probe, M14x1.5 thread, no armor
  • Configuration Code: 000-100-10-02-05
    • 000: Unthreaded length (00 mm)
    • 100: Case length (100.0 mm)
    • 10: Cable length (1.0 meter / 3.3 feet)
    • 02: Connector type (Miniature coaxial ClickLoc)
    • 05: Approval (Multiple Agency)

Technical Specifications

• Electrical & Performance
  • Probe DC Resistance (1.0m): 5.9 ohms ± 0.5 ohms
  • Magnetic Field Immunity (60Hz): Very low sensitivity (e.g., 0.009 mil pp/gauss at 2.5mm gap).
• Physical Construction
  • Probe Tip: Polyphenylene sulfide (PPS)
  • Probe Case: AISI 304 Stainless Steel
  • Case Thread: M14 x 1.5
  • Max Thread Engagement: 21 mm
  • Cable: 75 Ω triaxial, FEP insulated
• Environmental Ratings
  • Operating Temperature: -52°C to +177°C
  • Note: Do not expose below -34°C for long periods.
  • Installation Torque: Max: 63.3 N·m | Recommended: 21.1 N·m
• Certifications & Approvals
  • Code 05 indicates multiple agency approvals.
  • Suitable for various EPL (Ga, Gc, Dc) temperature classes.

Frequently Asked Questions (FAQ)

Ordering & Shipping

• What shipping options do you offer?

We use major carriers: FedEx, UPS, and DHL. You can choose your preferred service at checkout for fast global delivery.

• Does the 12-month warranty cover international orders?

Yes. The 12-month factory warranty is valid worldwide. Keep your original packing and invoice for any service claims.

Technical & Application

• What does “without armor” mean for model 330703?

It means the probe case does not have extra protective armor. This is standard for many internal mounting locations. Choose armored versions for harsher physical environments.

• Why are multiple agency approvals (option 05) important?

Option 05 means the probe meets safety standards for use in many countries. This simplifies procurement for global projects and ensures regulatory compliance.

• From experience, what is the most critical step during installation?

Setting the correct gap between the probe tip and the target shaft. Always use a micrometer and the monitor’s gap voltage setting. An incorrect gap leads to faulty readings.

Need help selecting the right probe? Contact our support team on WhatsApp for expert advice.
