Product Overview
Introducing the genuine Bently Nevada 3300 XL 11 mm Proximity Probes. This 330704-010-060-10-11-00 probe is perfect for precise vibration and position monitoring. It comes new and original in factory packaging with a full 12-month warranty. We ensure fast worldwide shipping via FedEx, UPS, or DHL.
Key Features & Benefits
- High Accuracy Sensing: Delivers reliable data for machine health.
- Robust Construction: Stainless steel case and durable PPS tip withstand harsh environments.
- Easy Integration: Standard M14x1.5 thread and ClickLoc connector simplify installation.
- Wide Temperature Range: Operates reliably from -52°C to +177°C.
- Superior Compatibility: Works seamlessly with 3300 XL monitoring systems.
Complete Technical Specifications
- Brand & Model: Bently Nevada 330704-010-060-10-11-00
- Core Function: 11 mm Proximity Transducer
- Electrical Data
- Probe DC Resistance: 5.9 ± 0.5 Ω (at 1.0 meter length)
- Cable Impedance: 75 Ω Triaxial
- Anti-Interference: Low output voltage shift in magnetic fields (e.g., 0.027 mil pp/gauss at 4.6 mm gap).
- Physical Construction
- Case Material: AISI 304 Stainless Steel
- Tip Material: Polyphenylene Sulfide (PPS)
- Thread: M14 x 1.5
- Unthreaded Length: 10 mm
- Overall Case Length: 60 mm
- Cable: 1.0 meter FluidLoc, FEP insulated
- Connector: Miniature Coaxial ClickLoc with protector
- Performance & Environment
- Temperature Range: -52°C to +177°C (Operational & Storage)
- Environmental Durability: Robust design for industrial settings.
- Installation Torque: Recommended 21.1 N•m (Max 63.3 N•m)
Installation & Maintenance Guide
- Mounting: Use the M14x1.5 thread. Do not exceed 21 mm thread engagement.
- Torque Carefully: Apply the recommended 21.1 N•m (187 in•lb) torque.
- Temperature Warning: Avoid exposing the probe below -34°C to protect the pressure seal.
- Maintenance: Visually inspect the cable and connector regularly for damage. Calibration is typically system-based.
Compatibility & Applications
- Primary Compatibility: Designed for Bently Nevada 3300 XL monitoring systems.
- Typical Applications:
- Vibration monitoring on turbines, compressors, and pumps.
- Shaft position and eccentricity measurement.
- Key phasor timing reference.
- Diagnostic Capability: Essential for predicting bearing wear, detecting imbalance, and identifying misalignment in rotating machinery.
Certifications & Package
- Agency Approvals: This variant (option 00) is for applications where specific agency approval is not required.
- What’s in the Box:
- One Bently Nevada 330704-010-060-10-11-00 Probe.
- Factory packaging and documentation.
- Warranty: Full 12-month factory warranty against defects.
Frequently Asked Questions (FAQ)
Product & Selection
- What is the exact part number for an 11mm probe with a 1m cable and M14 thread?
- You need the 330704-010-060-10-11-00. The suffix defines all options.
- How do I choose the right probe length?
- Consider the required gap and mounting space. The ‘010’ option gives 10mm of unthreaded length for standard applications.
Installation & Use
- What is the maximum torque for installation?
- The absolute maximum is 63.3 N•m. We strongly recommend using 21.1 N•m for optimal performance and safety.
- Can this probe be used in very cold environments?
- It operates down to -52°C. But avoid temperatures below -34°C during storage or handling to prevent seal damage.
- From experience, what is a common installation mistake?
- Overtightening the probe is common. Always use a calibrated torque wrench to avoid damaging the case or threads.
Ordering & Support
- What shipping methods are available?
- We ship globally via reliable carriers: FedEx, UPS, and DHL.
- I need technical help with my application. Who can I contact?
- For expert support, contact our engineers on WhatsApp at +86 158 8020 0923.
