Bently Nevada 330707-00-20-10-01-05 | Multi-Approved Compact Vibration Sensor

Description

Compact & Certified Industrial Vibration Probe

This Bently Nevada 3300 XL 11 mm Proximity Probe offers a certified, compact solution. It features a short 1-meter cable and 2-inch case with a 5/8-18 thread. Holding multiple international approvals, it is ready for global projects in controlled environments.

Key Product Highlights

• Globally Certified: Carries multiple agency approvals for international use.
• Compact & Robust: Short 2-inch case with a sturdy 5/8-18 thread.
• Protected Connection: ClickLoc connector includes a protective cover.
• Wide Operational Range: Functions from -51°C to +177°C.
• Standard Duty Cable: Reliable FEP-insulated cable for general use.

Model Configuration Breakdown: 330707-00-20-10-01-05

• Product Family Code
  • 330707 – 3300 XL 11mm Probe, 5/8-18 Thread, No Armor
• Selected Feature Set
  • Option 1 & 2: 00 – Unthreaded Length: 0.0 in
  • Option 3 & 4: 20 – Case Length: 2.0 in
  • Option 5 & 6: 10 – Cable Length: 1.0 meter
  • Option 7 & 8: 01 – Connector: ClickLoc with Protector, Standard Cable
  • Option 9 & 10: 05 – Agency Approvals: Multiple

Technical Specifications

• Product Information
  • Brand: Bently Nevada
  • Model: 330707-00-20-10-01-05
  • Type: 11mm Proximity Vibration Probe
• Electrical Data
  • Probe Resistance: 5.9 ± 0.5 Ohms (for 1m cable)
  • Cable Type: 75 Ω Triaxial, FEP Insulation
• Physical Design
  • Case Material: AISI 304 Stainless Steel
  • Tip Material: Polyphenylene Sulfide (PPS)
  • Mounting Thread: 5/8-18 UNF
  • Max Engagement: 0.938 inches
• Installation Parameters
  • Installation Torque: 15.2 N•m (133 in-lb)
  • Maximum Torque: 45.2 N•m (400 in-lb)
  • Connector Torque: Finger tight
  • Minimum Bend Radius: 25.4 mm
• Environmental Data
  • Full Temp Range: -51°C to +177°C (Operating & Storage)
  • Seal Caution: Exposure below -34°C may reduce seal life.
  • Pressure Seal: Viton O-ring (standard, not pressure tested).

Packaging & Service Details

• Package Contents:
  • 1 x Probe 330707-00-20-10-01-05
  • Connector with protective cover
• Warranty: Backed by a full 12-month manufacturer’s warranty.
• Shipping Options: Fast and reliable delivery via FedEx, UPS, and DHL.
• Unit Weight: 0.17 kg

Expert Questions & Selection Tips

What does “Multiple Approvals” mean for this probe?

It means the probe meets several international safety and performance standards. This is often required for projects in regulated industries or for export.

When should I choose a standard cable over a FluidLoc cable?

Choose the standard cable (Option -01) for dry, indoor, or clean environments. Choose FluidLoc for areas with oils, coolants, or moisture.

Why is the connector protector important?

It prevents damage to the delicate electrical pins during shipping, storage, and installation before the probe is connected to the system.

Is this probe suitable for hazardous locations?

The “-05” approval option indicates it has certifications often required for such areas. Always verify the specific approval matches your site’s classification.

What’s the first step in selecting the right probe?

Identify your mounting thread size (5/8-18 here) and required cable length. Then, determine if you need special approvals or fluid-resistant cable.
