Description
Long-Reach Precision for Industrial Monitoring
Meet the Bently Nevada 3300 XL 11 mm Proximity Probe, model 330707-00-20-90-01-00. Designed for critical vibration and position monitoring, this sensor delivers reliable data from hard-to-reach equipment. Its standout feature is the long 9-meter cable, perfect for large turbines, compressors, and generators where connection points are distant. Built with a rugged stainless steel case, it withstands harsh industrial environments to ensure your machinery’s health and prevent unexpected downtime.
Complete Product Configuration
- Product Identity & Core Use
- Brand & Series: Bently Nevada 3300 XL
- Full Part Number: 330707-00-20-90-01-00
- Sensor Type: 11 mm Eddy-Current Proximity Probe
- Primary Application: Non-contact measurement of shaft vibration and position.
- Part Number Decoder
- 330707: Base model for an 11 mm probe with 5/8-18 UNF thread, no armor.
- -00: Unthreaded length is 0.0 inches.
- -20: Overall case length is 2.0 inches.
- -90: Total cable length is 9.0 meters (key feature for long runs).
- -01: Miniature coaxial ClickLoc connector with protector.
- -00: No specific agency approvals required for this variant.
- Robust Physical Build
- Probe Tip: Polyphenylene sulfide (PPS) for durability.
- Probe Case: AISI 304 stainless steel for corrosion resistance.
- Thread Size: 5/8-18 UNF.
- Case Torque: Recommended 15.2 N•m (133 in•lb). Max 45.2 N•m.
- Cable Type: 75 Ω triaxial with FEP insulation.
- Shipping Weight: 0.17 kg.
- Performance & Environmental Specifications
- Probe Resistance (9m): 8.5 Ω ±1.1 Ω (center to outer conductor).
- Wide Temperature Range: Operates from -51°C to +177°C.
- Low-Temp Note: Exposure below -34°C may affect the internal pressure seal.
- Connection: ClickLoc connector; torque to finger tight (max 0.565 N•m).
- Cable Bend Radius: Minimum 25.4 mm (1.0 inch).
- Ordering & Service Information
- Availability: In stock and ready to ship.
- Global Shipping: FedEx, UPS, and DHL express options available.
- Warranty: Backed by a 12-month product warranty.
- Expert Support: Contact our engineers on WhatsApp for application advice.
Frequently Asked Questions
Product Selection & Use
Q: What is the main advantage of the 9-meter cable length?
A: It allows installation on large machinery where the monitor is far from the measurement point, reducing the need for extension cables.
Q: Can this probe measure both vibration and position?
A: Yes. When connected to a compatible Bently Nevada monitor system, it can measure radial vibration or axial position (thrust).
Installation & Compatibility
Q: What does “without armor” mean for the cable?
A: The cable has a standard FEP jacket instead of a braided stainless steel overjacket. It is suitable for general industrial use without extreme abrasion risk.
Q: Is this probe compatible with older Bently Nevada systems?
A: Yes, the 3300 XL 11 mm probes are designed for compatibility with 3300 XL monitoring systems. Check your system manual for specific requirements.
Technical & Purchasing Advice
Q: The probe resistance is 8.5Ω. Is this normal for a 9m cable?
A: Yes. Resistance increases with cable length. This value (8.5Ω ±1.1Ω) is the expected and correct specification for a 9-meter probe.
