Description
Bently Nevada 330707-00-20-90-02-05 Long-Range Probe
This is the genuine Bently Nevada 330707-00-20-90-02-05. It is a 9-meter long 3300 XL 11 mm Proximity Probe. Made in the USA with multiple safety approvals.
Product Configuration & Options
- Base Model: 330707 (3300 XL 11mm Probe, 5/8-18 UNF, Unarmored)
- Detailed Option Tree:
- Unthreaded Length: 00 → 0.0 in
- Case Length: 20 → 2.0 in
- Total Length: 90 → 9.0 meters (29.5 ft)
- Connector/Cable: 02 → ClickLoc connector, standard cable
- Agency Approval: 05 → Multiple Approvals
Core Specifications & Performance
- Measurement Type: 11mm Eddy Current Vibration/Position
- Thread Size: 5/8-18 UNF
- Cable Length: 9.0 meters (long-range)
- Cable Spec: 75 Ω Triaxial, FEP insulation
- DC Resistance: 8.5 ± 1.1 ohms (for 9m)
- Temperature Range: -51°C to +177°C
- Case Material: AISI 304 Stainless Steel
- Tip Material: Polyphenylene Sulfide (PPS)
- Weight: 0.17 kg
Installation & Handling Guide
- Mounting Torque: Tighten to 15.2 N•m (133 in•lb). Do not exceed 45.2 N•m.
- Max Thread Engagement: 0.938 inches for 5/8-18 thread
- Connector Torque: Finger tight only. Maximum 0.565 N•m.
- Minimum Bend Radius: Keep cable bends over 25.4 mm (1.0 in).
- Cold Weather Warning: Do not install below -34°C to avoid seal damage.
Professional FAQs & Support
Q: Where is a 9-meter probe typically used?
A: The 330707-00-20-90-02-05 is perfect for very large machines where the monitoring cabinet is far from the measurement point, such as in big power plants or on offshore platforms.
Q: What does “Multiple Approvals” mean?
A: Option 05 indicates this probe meets several international safety standards. This is important for use in regulated industries like oil & gas.
Q: Is this probe armored?
A: No. This specific model (330707) is without armor. Choose an armored version if the cable needs extra physical protection.
Q: What is your quality guarantee?
A: We offer a 12-month warranty on this Bently Nevada probe, covering any material or manufacturing defects.
Q: How are orders shipped and tracked?
A: All orders are shipped via reliable carriers like FedEx, UPS, or DHL. You will receive a tracking number as soon as your item is dispatched.
Need application advice? Message us on WhatsApp: +86 158 8020 0923
Explore more options in our collection of 3300 XL 11 mm Proximity Probes.
