Bently Nevada 330709-000-230-10-12-05 3300 XL 11 mm Proximity Probe

Description

Product Overview

• Brand: Bently Nevada
• Model: 330709-000-230-10-12-05
• Series: 3300 XL 11 mm Proximity Probes
• Made in: U.S.A
• Total Length: 1.0 meter (3.3 feet)
• Connector: Miniature coaxial ClickLoc connector with FluidLoc cable
• Agency Approval: Multiple approvals (type 05)
• Applications: Precision vibration and shaft monitoring in industrial settings

Model Configuration

• 330709
  • 11 mm probe, M16 x 1.5 thread, without armor
• 000
  • Unthreaded length: 0 mm
• 230
  • Overall case length: 230 mm
• 10
  • Total length: 1.0 meter (3.3 feet)
• 12
  • Miniature coaxial ClickLoc connector with FluidLoc cable
• 05
  • Multiple agency approvals

Technical Specifications

• Probe Resistance: 5.9 ± 0.5 Ω
• Thread Size: M16 x 1.5
• Thread Engagement: Maximum 24 mm
• Probe Case Torque:
  • Recommended: 21.1 N·m (187 in·lb)
  • Maximum rated: 63.3 N·m (560 in·lb)
• Temperature Range: -52°C to +177°C
• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 304 stainless steel
• Cable: 75 Ω triaxial, FEP insulated cable
• Minimum Bend Radius: 25.4 mm
• Cross-talk Limitation: Effective for flat surfaces with a minimum diameter of 30.5 mm and shaft diameters of at least 152 mm

Temperature Classification

• For EPL Ga and Gc:
  • T1: -55°C to +232°C
  • T2: -55°C to +177°C
  • T3: -55°C to +120°C
  • T4: -55°C to +80°C
  • T5: -55°C to +40°C
• For EPL Dc:
  • T280°C: -55°C to +232°C
  • T225°C: -55°C to +177°C
  • T170°C: -55°C to +120°C
  • T130°C: -55°C to +80°C
  • T105°C: -55°C to +100°C
  • T90°C: -55°C to +40°C

Installation Guidelines

• Align the probe properly for accurate measurements and ensure a secure installation.
• Torque the probe casing to 21.1 N·m (recommended torque) to ensure a tight connection.
• Maintain a minimum bend radius of 25.4 mm for optimal cable performance.
• Ensure the connector is properly tightened, finger-tight is sufficient for most installations.

Maintenance & Commissioning

• Check probe resistance regularly to ensure it stays within the expected range.
• Inspect the cable for wear and tear to prevent signal disruptions.
• Monitor the probe’s performance to ensure consistent and reliable operation.
• Follow the temperature guidelines to prevent any damage to the probe’s seals or components.

Frequently Asked Questions

• What makes the Bently Nevada 3300 XL probe ideal for industrial use?
  The 3300 XL probe offers high precision, rugged construction with multiple agency approvals, and superior temperature resistance, making it perfect for harsh industrial environments.
• Can the 1-meter length be used in compact equipment?
  Yes, the 1-meter probe is designed for use in smaller systems or equipment where space is limited but accurate vibration monitoring is still required.
• How does the FluidLoc cable enhance probe performance?
  FluidLoc cable provides extra protection against moisture and environmental hazards, ensuring long-lasting and reliable signal transmission.
• What shipping options are available?
  We offer shipping via FedEx, UPS, and DHL. Delivery times may vary depending on your location. Please contact us for details.
• What warranty comes with this product?
  The product is covered by a 12-month warranty, ensuring peace of mind and reliable service throughout its lifetime.
