Bently Nevada 330881-28-00-095-05-01 | PROXPAC XL Proximity Transducer

Description

A high-precision 8 mm proximity sensor (330881-28-00-095-05-01) designed for industrial machinery monitoring. Built with stainless steel housing, UV-resistant PPS thermoplastic, and gold-plated connectors for durability in harsh environments. Includes a 95 mm probe penetration and IP66-rated housing certified by BASEEFA.

Technical Data

• Brand: Bently Nevada
• Model: 3300 XL Proximity Transducer – 330881-28-00-095-05-01
• Suffix Details:
  • Probe Option: 28 (8 mm with Multiple Approvals)
  • Standoff Adapter: 00 (No adapter)
  • Penetration: 095 (95 mm)
  • Fittings: 05 (PG21 to PG11 reducer + plugs)
  • Mounting: 01 (M24 X 3 thread)
• Operating Temp: -51°C to +177°C (-60°F to +350°F)
• Power Supply: -17.5 Vdc to -26 Vdc, 12 mA max
• Linear Range: 2 mm (80 mils)
• Frequency Response: 0-10 kHz (±3 dB)
• Certifications: BASEEFA, CSA, IP66
