Description
Long-Reach Machine Health Sensor
This Bently Nevada 3300 NSv Proximity Probe is built for deep mounting. Its 9-inch case reaches into tight spaces. It delivers precise vibration data for predictive maintenance. Trust it for reliable monitoring of critical assets.
Key Benefits for Your Operation
- Deep Access Design: 9.0-inch case length reaches difficult measurement points. Ideal for deep bore or casing applications.
- Globally Certified: Features “Multiple Approvals” agency option. Meets stringent international standards for wider acceptance.
- Compact Cable Run: 0.5-meter cable minimizes excess in control panels. Keeps installations neat and organized.
- Extreme Environment Ready: Performs from -52°C to +177°C. Handles thermal shock and harsh conditions.
- Plug-and-Play Compatibility: Standard ClickLoc connector works with 3300 NSv monitors. Ensures quick integration.
Model Number Breakdown
Your Product Code: 330901-00-90-05-02-05
- 330901 – 3300 NSv Probe, 1/4-28 UNF, No Armor
- ⚬ 00 – Unthreaded Section
- Setting: 0.0 in
- ⚬ 90 – Probe Body
- Length: 9.0 in
- ⚬ 05 – Attached Cable
- Length: 0.5 m (20 in)
- ⚬ 02 – End Connection
- Type: ClickLoc Coaxial
- ⚬ 05 – Safety Certifications
- Status: Multiple Approvals
- ⚬ 00 – Unthreaded Section
Critical Technical Details
- Electrical Performance:
- Probe Resistance (0.5m): 4.0 Ω ± 0.5 Ω
- Cable Type: 75 Ω, FEP Coaxial
- Construction & Mounting:
- Case: AISI304 Stainless Steel
- Tip: PPS (Polyphenylene Sulfide)
- Seal: Viton O-Ring
- Thread: 1/4-28 UNF
- Torque Spec: 11.3 N·m (100 in-lb)
- Operational Limits:
- Temperature: -52°C to +177°C (Op/Storage)
- Caution: Limit time below -34°C to protect seal.
- Safety Ratings: EPL Ga/Gc/Dc (Full T-Class)
- Weight: Approx. 14–150 g
Installation Guide
Install the probe into a 1/4-28 UNF threaded hole. Ensure full thread engagement without exceeding limits. Torque to 100 in-lb. Connect the short 0.5m cable to the monitor. Questions? Chat with our experts on WhatsApp: +86 158 8020 0923.
Package & Service Info
- One (1) Bently Nevada 330901-00-90-05-02-05 proximity probe.
- Factory-attached 0.5-meter cable with ClickLoc connector.
Shipping Options: We deliver via FedEx, UPS, and DHL worldwide.
Warranty Coverage: Includes a standard 12-month manufacturer warranty.
Frequently Asked Questions
What does “Multiple Approvals” (option 05) include?
This means the probe is manufactured and tested to meet several international certification bodies’ requirements beyond the standard. It is suitable for projects demanding specific global approvals.
When should I choose the 9.0-inch case length?
Select the -90 option when you need to mount the probe through a thick machine casing, wall, or insulation to reach the measurement target (e.g., a shaft) deep inside the equipment.
Is the 0.5m cable length sufficient?
The -05 cable (0.5m) is ideal when the monitor is installed very close to the probe mounting point, such as in a local junction box. It reduces cable clutter.
How are warranty returns handled for international customers?
If your 330901-00-90-05-02-05 probe has a defect within 12 months, contact us. We will provide a return authorization and a prepaid shipping label from a major carrier like UPS for a smooth process.
What is a best practice for storing this probe before use?
Store the probe in its original packaging in a dry, room-temperature environment. Avoid storing in unheated sheds where temperatures may drop below -34°C for long periods, as this can compromise the seal.
