Bently Nevada 330903-00-02-05-12-05 3300 NSv Proximity Probe

Description

Bently Nevada 3300 NSv Proximity Probe – High-Performance Vibration Monitoring

Description

New & original Bently Nevada 330903-00-02-05-12-05 proximity probe in factory packaging. Features enhanced chemical resistance and superior side-view characteristics for process compressors. 12-month warranty included.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 NSv Probe
• Full Part No: 330903-00-02-05-12-05
• Range: 1.5mm linear (0.25-1.75mm)
• Accuracy: < ±0.06mm DSL
• Output: -1 to -13 Vdc
• Scale Factor: 7.87 V/mm (±12.5%/-20%)
• Cable: 0.5m with ClickLoc connector

Installation Guide

• Optimal gap: 1.0 mm (40 mils)
• Max torque: 0.56 N•m (5 in•lb)
• Min target size: 13mm diameter
• Min bend radius: 25.4mm

Compatibility

Direct replacement for 3300 RAM probes and cables. Superior chemical resistance and side-view performance vs older models.

Certifications

Multiple agency approvals (Suffix: -05). Complies with international industrial standards.

Packaging & Warranty

• Factory-sealed original packaging
• 12-month manufacturer warranty
• Includes probe with 0.5m cable and connector

Shipping

Ships worldwide via FedEx, UPS, DHL. Tracking provided for all orders.

FAQ

Q: Is this compatible with 3300 RAM systems?
A: Yes – fully interchangeable with existing 3300 RAM probes.

Q: What cable length options exist?
A: Available in 0.5m (this model), 1m, 5m and 7m variants.

Q: Pressure rating?
A: Features Viton O-ring seal. Contact for pressure testing requirements.
