Description
Compact M8X1 Thread Probe for Precision Monitoring
Product Snapshot
New condition. Original factory packing. This 330903-00-02-10-01-05 model features:
- Small M8X1 metric thread
- Short 20mm case length
- 1-meter cable with protector
- Enhanced chemical resistance
Key Measurements
| Measurement Range | 1.5mm (60 mils) |
| Best Gap Setting | 1.0mm (40 mils) |
| Voltage Output | 7.87 V/mm ±20% |
| Accuracy | ±0.06mm (±2.3 mils) |
| Response Speed | 0-10 kHz range |
Electrical Properties
- Probe Resistance: 4.2Ω ±0.5
- Cable Resistance: 0.220 Ω/m (center)
- Shield Resistance: 0.066 Ω/m
- Cable Capacitance: 69.9 pF/m
- Max Wiring Length: 305 meters
Physical Specifications
- Case Size: 20mm (compact)
- Thread Type: M8X1 metric
- Bend Radius: 25.4mm minimum
- Torque Limit: 5.1 N•m max
- Thread Depth: 12mm maximum
Special Advantages
- Better chemical resistance than older RAM probes
- Superior side-view performance
- Works with existing 3300 systems
- Small target capability (8.9mm minimum)
Package & Support
- Condition: New in original box
- Warranty: 12 months full coverage
- Shipping: FedEx, UPS, DHL options
Common Questions
Q: How small a target can it measure?
A: Minimum 8.9mm diameter (13mm recommended).
Q: Is it compatible with older systems?
A: Yes – works with previous 3300 RAM systems.
Q: Why choose M8X1 thread?
A: Perfect for compact equipment and metric fittings.
