Description
Bently Nevada 3300 NSv M8 Probe: 30mm Sensor with Protected FluidLoc Cable
New factory-sealed vibration probe with M8X1 threading and armored connector. Features FluidLoc cable technology for challenging industrial environments. Includes 12-month warranty.
Product Identification
- Base Code: 330903
- Unthreaded Length: 00 (0 mm)
- Case Length: 03 (30 mm)
- Cable Length: 10 (1.0 meter)
- Connection System: 11 (ClickLoc with protector + FluidLoc)
- Certifications: 00 (Not required)
Technical Specifications
- Thread Type: M8X1 metric
- Cable Technology: FluidLoc chemical-resistant
- Connector Protection: Impact-resistant cover
- Measurement Range: 0.25-1.75 mm (10-70 mils)
- Scale Factor: 7.87 V/mm ±20%
- Linearity Deviation: <0.06 mm
- Frequency Range: DC to 10 kHz
- Electrical Resistance: 4.2Ω ±0.5
- Capacitance: 69.9 pF/m
- Min Target Size: 8.9 mm diameter
Installation Specifications
- Recommended Gap: 1.0 mm (40 mils)
- Mounting Torque: 5.1 N•m (45 in•lb)
- Thread Engagement: Max 12 mm
- Bend Radius: Min 25.4 mm
- Field Wiring: Up to 305 meters
Environmental Ratings
- Operating Temp: -52°C to +177°C
- Chemical Resistance: Enhanced FluidLoc protection
- Sealing System: Viton O-ring
- Vibration Tolerance: 10g @ 10-2000 Hz
- Shock Resistance: 100g @ 11ms
Performance Advantages
- 25% better chemical resistance than previous RAM probes
- 15% wider side-view detection angle
- Faster response time for transient events
- Reduced signal noise in electrically noisy environments
- Backward compatible with 3300 RAM systems
Package Contents
- 1x M8 threaded probe
- 1x 1.0m FluidLoc cable
- 1x ClickLoc connector with protector
- Installation documentation
- 12-month warranty certificate
Global Delivery
Ships worldwide via FedEx, UPS or DHL with full tracking.
