Bently Nevada 330903-00-04-05-12-05 Proximity Probes Without Armor

Description

Bently Nevada 3300 NSv Proximity Probe – Industrial Vibration Monitoring Solution

New OEM sensor with enhanced chemical resistance for critical machinery protection.

Complete Suffix Breakdown

• Base Model: 330903 (M8X1 thread, no armor)
• -00-: 0mm unthreaded length
• -04-: 40mm case length
• -05: 0.5m cable length
• -12: ClickLoc connector + FluidLoc cable
• -05: Multiple agency approvals

Enhanced Technical Specifications

• Brand/Model: Bently Nevada 330903-00-04-05-12-05
• Cable Specs: 75Ω FEP coaxial
• Resistance: Center 0.220 Ω/m, Shield 0.066 Ω/m
• Capacitance: 69.9 pF/m typical
• Frequency: 0-10 kHz (±3dB)
• Linearity: ±0.06mm deviation
• Materials: PPS tip, 304 SST case
• Bend Radius: 25.4mm minimum

Installation Parameters

• Optimal Gap: 1.0mm (40 mils)
• Torque Limit: 0.56 N•m (5 in•lb)
• Thread Engagement: Max 12mm
• Wiring: 0.2-1.5mm² shielded triad
• Max Run: 305m (1000ft)

Compatibility & Performance

• Direct replacement for 3300 RAM systems
• 30% better chemical resistance than RAM probes
• Improved side-view characteristics
• Maintains accuracy on shafts ≥13mm diameter

Certifications & Compliance

International approvals for hazardous locations (ATEX/IECEx)

Packaging & Support

• Factory-sealed with Viton O-ring
• 12-month manufacturer warranty
• Global shipping: FedEx Priority, UPS Saver, DHL Express

Technical FAQ

Q: FluidLoc vs standard cable?
A: FluidLoc provides superior chemical resistance in oil/gas environments

Q: Minimum bend radius for installation?
A: Maintain ≥25.4mm (1″) radius at all points

Q: Pressure testing available?
A: Custom testing upon request (contact engineering)

Q: Effect of long cable runs?
A: Signal rolloff occurs beyond 305m – use repeaters

Q: Small shaft measurement solution?
A: Reduce gap to 0.75mm and recalibrate scale factor
