Description
330903-00-04-10-01-00: Extended M8 Vibration Probe
40mm case sensor with standard cable. Precision vibration monitoring for industrial machinery. New original Bently Nevada product.
Configuration Tree
- ├─ Base: 330903 (M8X1 thread)
- ├─ 00: Zero unthreaded length
- ├─ 04: 40mm case length
- ├─ 10: 1.0m cable
- ├─ 01: Standard ClickLoc connector
- └─ 00: No approvals needed
Technical Highlights
- Extended reach: 40mm case for deeper installations
- Cable resistance: Center 0.220 Ω/m, Shield 0.066 Ω/m
- Voltage output: -1 to -13 Vdc across linear range
- ±0.06mm measurement precision
Performance Specifications
| Parameter | Specification |
|---|---|
| Response Frequency | 0-10 kHz (±3dB) |
| Signal Rolloff | Minimal up to 305m wiring |
| Scale Factor Tolerance | +12.5%/-20% |
| Pressure Seal | Viton O-ring (differential) |
Model Comparison
| Feature | This Model | 00-05-05-01-00 | 00-05-05-11-00 |
| Case Length | 40mm | 50mm | 50mm |
| Cable Length | 1.0m | 0.5m | 0.5m |
| Cable Type | Standard | Standard | FluidLoc |
| Installation Depth | Medium | Deep | Deep |
Installation Guide
- Optimal gap: 1.0mm from target surface
- Torque: Finger tight to 0.56 N•m max
- Max thread engagement: 12mm
- Min bend radius: 25.4mm
Compatibility
Direct replacement for 3300 RAM probes with enhanced side-view characteristics.
Package Contents
- M8 vibration probe (40mm case)
- 1.0m standard FEP cable
- ClickLoc connector with protector
- 12-month manufacturer warranty
Global Shipping
DHL | FedEx | UPS – Worldwide delivery
FAQ
- Q: Why choose 40mm case length?
A: Ideal for medium-depth installations requiring stability - Q: Signal quality over long wiring?
A: Maintains response up to 305m with proper shielded cable - Q: Chemical resistance compared to RAM probes?
A: Enhanced PPS tip material withstands harsh environments
