Bently Nevada 330903-00-05-05-01-00 Proximity Probes Without Armor

Description

Bently Nevada 330903-00-05-05-01-00: Precision NSv Proximity Probe

Industrial-grade vibration monitoring with M8X1 threaded design. New original unit with full factory warranty.

PRODUCT IDENTIFICATION

• Part Number: 330903-00-05-05-01-00
• Model: 3300 NSv Proximity Probe
• Manufacturer: Bently Nevada
• Condition: New in factory packaging
• Warranty: 12 months

CONFIGURATION BREAKDOWN

• Base Model
  • 330903: NSv Probe, M8X1 thread, no armor
• Length Options
  • -00-: 00 mm unthreaded length
  • -05-: 50 mm overall case length
  • -05: 0.5 meter (20 in) total length
• Connection System
  • -01: Miniature coaxial ClickLoc connector with protector
• Certification
  • -00: No agency approvals required

PERFORMANCE SPECIFICATIONS

• Electrical Properties
  • Probe Resistance: 4.0Ω ±0.5Ω (0.5m length)
  • Cable Capacitance: 69.9 pF/m typical
  • Frequency Response: 0-10kHz (±3dB with 1000ft wiring)
• Mechanical Properties
  • Tip Material: Chemical-resistant PPS polymer
  • Case Material: AISI 304 stainless steel
  • Min Bend Radius: 25.4mm (1.0in)
  • Max Torque: 0.56 N•m (5 in•lb)
• Measurement Performance
  • Linear Range: 0.25-1.75mm (10-70 mils)
  • Scale Factor: 7.87 V/mm (±12.5%/-20%)
  • Deviation: < ±0.06mm (±2.3 mils)
• Environmental Ratings
  • Operating Temp: -52°C to +177°C (-62°F to +351°F)
  • Ingress Protection: Viton O-ring pressure seal

INSTALLATION GUIDE

• Mounting: M8X1 thread (max 12mm engagement)
• Torque Specs:
  • Recommended: 5.1 N•m (45 in•lb)
  • Maximum: 7.3 N•m (65 in•lb)
• Gap Setting: Optimal at 1.0mm (40 mils)
• Wiring: Use shielded triad cable (max 305m/1000ft)

COMPATIBILITY

• Direct replacement for 3300 RAM probes
• Works with Bently Nevada monitoring systems
• Superior side-view characteristics vs 3000-series 190 probes

PACKAGE CONTENTS

• 330903-00-05-05-01-00 probe unit
• ClickLoc connector protector

SUPPORT & DELIVERY

• Warranty: 12-month manufacturer coverage
• Shipping: FedEx, UPS, DHL with tracking
• Lead Time: In stock for immediate dispatch

TECHNICAL FAQ

Q: What’s the minimum target size?
A: Minimum 8.9mm diameter, recommended 13mm for accurate readings.

Q: Can it handle chemical exposure?
A: Yes, PPS tip provides superior chemical resistance vs older models.

Q: What cable length options exist?
A: Available in 0.5m (this model), 1m, 5m and 7m configurations.

Q: Is pressure testing included?
A> Units ship untested – contact us for custom pressure validation.

Q: How does it compare to 3300 RAM probes?
A: Fully compatible with improved chemical resistance and side-view performance.
