Description
3300 NSv Proximity Probe – Precision Measurement Solution
Product Overview
New Bently Nevada 330903-00-05-10-12-05 proximity probe with 12-month warranty. Features M8X1 thread, 1.0m FluidLoc cable, and miniature coaxial ClickLoc connector. Factory sealed packaging ensures original quality. Provides superior chemical resistance and compatibility with 3300 RAM systems.
Technical Specifications
| Brand | Bently Nevada |
| Full Model | 330903-00-05-10-12-05 |
| Measuring Range | 1.5 mm (60 mils) |
| Scale Factor | 7.87 V/mm ±12.5%/-20% |
| Output Signal | -1 to -13 Vdc linear range |
| Accuracy | ±0.06 mm deviation |
| Temp Range | -52°C to +177°C |
| Resistance | 4.2 Ω ±0.5 (1m cable) |
| Thread Type | M8X1 without armor |
Key Features
- Increased chemical resistance vs older models
- Superior side-view characteristics
- 75Ω coaxial FEP-insulated cable
- Stainless steel case with PPS tip
- Multiple agency approvals (Option 05)
Installation Guide
Recommended gap: 1.0 mm (40 mils)
Torque settings:
- Probe: Finger tight (max 0.56 N•m)
- Connector: 5.1 N•m recommended (7.3 N•m max)
Minimum bend radius: 25.4 mm (1.0 in)
Thread engagement: 12 mm max
Compatibility
Fully compatible with Bently Nevada’s 3300 RAM proximity probes and extension cables. Direct replacement for legacy systems.
Packaging & Warranty
New in factory packaging with 12-month manufacturer warranty. Ships worldwide via FedEx, UPS, DHL.
FAQ
Q: What cable length options exist?
A: Available in 0.5, 1, 5, or 7 meter lengths
Q: Minimum target size?
A: 8.9 mm diameter minimum (13 mm recommended)
Q: Pressure rating?
A: Seals differential pressure (Viton O-ring), contact for pressure testing
Q: Field wiring requirements?
A: Use shielded triad cable (max 305m/1000ft)
