Product Introduction
Discover the Bently Nevada 330903-00-06-05-02-CN. This is a new 3300 NSv proximity probe. It is perfect for precise vibration and position measurement in industrial machinery.
Complete Model Breakdown
- Core Model: 330903 – 3300 NSv M8x1 Probe
- Full Part Number: 330903-00-06-05-02-CN
- -00: Unthreaded Length = 00 mm
- -06: Case Length = 60 mm
- -05: Cable Length = 0.5 meter
- -02: Connector = Miniature Coaxial ClickLoc
- -CN: Country Specific Agency Approval
Key Product Specifications
- Brand & Series: Bently Nevada 3300 NSv
- Measurement Range: 1.5 mm (60 mils) linear
- Best Gap Setting: 1.0 mm (40 mils)
- Sensitivity Output: 7.87 V/mm (200 mV/mil)
- Response Frequency: 0 to 10 kHz
- Probe Resistance: 4.0 ± 0.5 Ohms
- Cable Capacitance: 69.9 pF/m typical
- Temperature Range: -52°C to +177°C
- Case Material: Strong AISI 304 Stainless Steel
- Tip Material: Chemical-Resistant PPS Plastic
- Mounting Thread: M8 x 1 mm
Why Choose This Probe?
- Proven Compatibility: Directly replaces older 3300 RAM probes. No system changes needed.
- Better Chemical Resistance: Ideal for process compressors with oil or gas exposure.
- Superior Signal Quality: Excellent side-view characteristics for stable measurements.
- Quick & Easy Connection: Standard ClickLoc connector for fast installation.
- Flexible Ordering: -CN option adapts to local market certification needs.
Installation & Connection Guide
- Mount using M8x1 thread. Use hand tight force (5 in-lb max torque).
- For axial position, aim for a 1.0 mm gap.
- Use shielded triad cable for field wiring (max 305 meters).
- Ensure target diameter is at least 13 mm for best accuracy.
- Avoid bending the cable tighter than 1.0 inch radius.
Order & Support Information
- Condition: 100% New, in Original Factory Packing.
- Warranty: Full 12-Month Manufacturer Warranty.
- Shipping: Fast worldwide delivery via FedEx, UPS, or DHL.
Frequently Asked Questions
Can I use this probe to replace my old 3300 RAM sensor?
Yes. The 330903-00-06-05-02-CN is a direct mechanical and electrical replacement. You can upgrade your system without any modifications.
What does the “-CN” approval option mean?
This means the probe is built to meet specific agency requirements for certain countries. Please contact us to confirm it matches your local safety standards.
Is this probe good for measuring small shafts?
For small shafts under 13mm, the output may change. We recommend using a smaller gap setting to help keep the signal accurate.
How do I connect the cable to the monitoring system?
This probe uses a standard ClickLoc connector. It plugs directly into compatible Bently Nevada proximitor modules. The connection is secure and simple.
What is the main advantage over the older 3000 series probes?
The 3300 NSv probe gives you a much better signal when mounted close to other metal objects. This reduces measurement error in tight spaces.
How to Buy the Right Model
Your exact part number is 330903-00-06-05-02-CN. Check you need M8 thread, 0.5m cable, and ClickLoc connector. For different cable lengths or thread types, please ask our team. We help you select the perfect match.
